PANEL
Screen Size 65"Panel Technology IPS
Native Resolution 3840 x 2160 (UHD)Brightness 700nit (Typ.)
Contrast Ratio 1,100:1Dynamic CR 500,000:1
Color gamut BT709 95%Viewing Angle(H x V) 178x178
Color Depth 10bit, 1.07Billion colorsResponse Time 8ms (G to G)
Surface Treatment(Haze) 28%Operation Hours (Hours/Day) 24/7
Portrait / Landscape Yes / Yes
CONNECTIVITY
Input HDMI (2, HDCP 2.2/1.4), HDMI (1, HDCP 1.4), DP (1, HDCP 2.2/1.3), DVI-D (HDCP 1.4), Audio, USB 2.0 Type AOutput DP, Audio
External Control RS232C (4 Pin Phone Jack) In / Out, RJ45(LAN) In, IR In
MECHANICAL SPECIFICATION
Bezel Color BlackBezel Width T/R/L: 9.9mm, B: 14.4mm
Weight(Head) 28.2KgMonitor Dimension(W x H x D) 1453.3 x 844.0 x 39.9mm
Monitor Dimensions with Stand(W x H x D) 1453.3 x 893.1 x 290.0mmHandle No
VESATM Standard Mount Interface 300 x 300
KEY FEATURE
Key features Internal Memory 8 GB, Built-in Wi-Fi, Temperature Sensor, Auto Brightness Sensor, Acceleration (Gyro) Sensor, Local Key Operation, webOS 4.1,Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Background Image (Booting Logo Image, No Signal Image),Sync Mode (RS232C Sync, Local Network Sync), Multi-screen (PIP, PBP (4)), Screen Share, Video Tag (4), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, Crestron Connected®2), Smart Energy Saving, PM Mode, Wake on LAN, Beacon, HDMI-CEC3), SI Server Setting, webRTC, Pro:Idiom
ENVIRONMENT CONDITIONS
Operation Temperature 0 °C to 40 °COperation Humidity 10 % to 80 %
POWER
Power Supply AC 100-240V~, 50/60HzPower Type Built-In Power
POWER CONSUMPTION
Typ. 130W(TBD)Max. 180W(TBD)
BTU (British Thermal Unit) 0 BTU/Hr(Typ.), 0 BTU/Hr(Max)
SOUND
Speaker Yes
CERTIFICATION
Safety CB / NRTLEMC FCC Class "A" / CE / KC
ErP / Energy Star Yes / Energy Star 8.0
OPS COMPATIBILITY
OPS Type Compatible YesOPS Power Built In No
SOFTWARE COMPATIBILITY
SuperSign CMS YesSuperSign Control / Control+ Yes / Yes
SuperSign WB YesSuperSign Media Editor Yes
LG ConnectedCare Yes
ACCESSORY
Basic Remote Controller, Power Cord, QSG, HDMI Cable, Regulation Book, Phone to RS232C GenderOptional Stand(ST-653T), Wall bracket(LSW350B), VESA Adapter(AM-B330S), OPS Kit(KT-OPSF)
SPECIAL FEATURE
Tilt(Facedown) Yes (Max 30º degree)
*In conditions within 30ºC temperature, 50% humidityIP Rating IP5x
