Hard Coating (3H), Anti-Glare Treatment of the Front Polarizer (Haze 10%)
Life time (Typ.)
50,000 Hrs min.
Operation Hours
24 Hrs / 7 Days
Orientation
Portrait & Landscape
CONNECTIVITY
Input
HDMI (2), DP, DVI-D, Audio in, OPS
External Control
RS232C in/out, RJ45, IR / Light sensor, Pixel sensor, USB 3.0
Output
DP, External Speaker out
PHYSICAL SPECIFICATION
Bezel Color
Black
Bezel Width
7.4 mm (T/L/R/B even)
Monitor Dimension (W x H x D)
1,095 x 637 x 32 mm
Weight (Head)
15.6 kg
Monitor with Optional Stand Dimensions (W x H x D)
1,095 x 700 x 298 mm
Weight (Head + Stand)
17.0 kg
Carton Dimensions (W x H x D)
1,197 x 760 x 134 mm
Packed Weight
18.7 kg
VESA TM Standard Mount Interface
400 x 400 mm
SPECIAL FEATURES
Yes
Temperature sensor, Auto brightness sensor, Tile Mode, DPM select, DPM wake up, Energy saving, Smart energy saving, File play with USB, PIP/PBP(2), Internal memory 16GB (System 4GB + Available 12GB), Wi-Fi dongle ready (802.11n) , USB cloning, Fail over
ENVIRONMENTAL CONDITIONS
Operating Temperature
0°C t o 40°C
Operating Humidity
10% t o 80%
POWER
Power Supply
100–240V~, 50/60Hz
Power Type
Built-in Power
Power Consumption-Typ
125 W (TBD)
Power Consumption Smart Energy Saving
90 W (TBD)
STANDARD (CERTIFICATION)
Safety
UL / cUL / CB / TUV / KC
EMC
FCC Class "A" / CE / KCC
ErP / Energy Star
NA / Yes (Energy Star 7.0)
MEDIA PLAYER COMPATIBILITY
OPS Type Compatible
Yes
External Media player Attachable
Yes (MP500/MP700)
SOFTWARE COMPATIILITY
SuperSign W/Lite
Yes
SuperSign C
Yes
ACCESSORIES
Basic
Remote controller (2ea batteries included), Power cord, IR/Light sensor receiver, QSG, Regular book (depend on regional standard), HDMI cable
