Panel
Screen Size 55"
Panel Technology OLED
Native Resolution 1,920 × 1,080 (FHD)
Brightness 150/400 nit (APL 100% / 25%)
Contrast Ratio 150,000 : 1
Color gamut BT709 120%
Viewing Angle (H x V) 178 × 178
Color Depth 10 bit (R), 1.07 Billion Colors
Response Time 1 ms (G to G), 8 ms (MPRT)
Surface Treatment (Haze) Hard Coating (2 H)
Reflectance Typ. 1.2%
Operation Hours (Hours / Day) 18 / 7 (Moving Content Only)
Portrait / Landscape Yes / Yes
Connectivity
Input HDMI (HDCP 1.4), DP (HDCP 1.3), USB 2.0 Type A (2)
Output DP, Audio
External Control RS232C In / Out (w/ IR Out), RJ45 (LAN) In / Out, IR In (External IR Receiver)
Mechanical Specification
Bezel Color Black
Bezel Width *TBD
0.9 mm (Even Bezel) (Off Bezel)
5.3 / 11.0 / 5.3 / 5.3 mm (T/R/L/B) (On Bezel)
Weight (Head) *TBD
6.6 kg (Head)
3.4 kg (Signage Box)
Monitor Dimension (W × H × D) *TBD
1,220.3 × 696.8 × 4.9 mm (Head)
782.8 × 238.4 × 34.7 mm (Signage Box)
Monitor Dimensions with Stand (W × H × D) No
VESA™ Standard Mount Interface No
Feature
Key Feature Internal Memory (16 GB), Temperature Sensor, webOS 4.0, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Sync Mode (RS-232C Sync, Local Network Sync), Video Tag (4), Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting, Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, Crestron Connected® (Network based control), Power (PM Mode, Wake on LAN), HDMI-CEC (Compatibility may differ by equipment), SI Server Setting, Pro:Idiom
Environment Conditions
Operation Temperature 0°C to 40°C
Operation Humidity 10% to 80%
Power
Power Supply AC 100-240 V ~, 50/60 Hz
Power Type Built-In Power
Power Consumption (Typ. / Max.) 309 W / 318 W
Power Consumption (Smart Energy Saving) 1,054 BTU/Hr (Typ.), 1,085 BTU/Hr (Max.)
Certification
Safety IEC 60950-1 / EN 60950-1 / UL 60950-1
EMC FCC Class "A" / CE / KC
ErP Yes
Software Compatibility
SuperSign CMS Yes
SuperSign Control / Control+ Yes
SuperSign WB Yes
SuperSign Media Editor Yes
LG ConnectedCare Yes * The availability can differ by region.
Sound
Speaker No
Accessory
Basic Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS232C Gender, RS232 Cable (4p-4p), FFC Cables (1,600 mm × 4 EA for Connection between Panel and Signage Box), DP Cable, LAN Cable, LC (VLC Cable), Wall Fixer (4 EA), Wall Fixer Install Guide, Install Guide Sheet (2 EA), Tape (10 EA for Cabling / 2 EA for Dust Proof), Screw (M4 × L25, 10 EA / M3 × L5.5, 8 EA)
