Monitor OLED LG Flexible Curved Open Frame 55EF5F-P
Panel
Screen Size: 55"
Panel Technology: OLED
Native Resolution: 1,920 x 1,080 (FHD)
Brightness: 150 / 400 nit (APL 100% / 25%)
Contrast Ratio: x150,000 : 1
Dynamic CR: No
Color gamut: BT709 120 %
Viewing Angle (H x V): 178 x 178
Color Depth: 1.07 Billion Colors (10bit)
Response Time: 1 ms (G to G)
Surface Treatment (Haze): No
Operation Hours (Hours / Day): 18 / 7 (Moving Content Only)
Orientation: Landscape & Portrait
Connectivity
Input: HDMI (HDCP 2.2), DP (HDCP 1.3), USB 2.0 Type A (2)
Output: DP, Audio
External Control: RS232C In / Out, RJ45 In / Out, IR In (External IR Receiver)
Mechanical Specification
Bezel Color
Black
Bezel Width (T / R / L / B)
0.6 / 6.7 / 6.7 / 0.6 mm (Off Bezel)
5.0 / 13.2 / 7.8 / 5.0 mm (Off Bezel)
Weight (Head)
7.8 kg
(Signage Box) 3.5 kg
Monitor Dimension (W × H × D)
701.4 x 1,219.7 x 38.0 mm (Head, w/Pemnut)
701.4 x 1,219.7 x 12.4 mm (Head, w/o Pemnut)
(Signage Box) 413 x 353 x 57.3 mm
Monitor Dimensions with Stand (W × H × D)
No
VESA™ Standard Mount Interface
No
Feature
Special Features: Internal Memory (64GB), Temperature Sensor, FAN, webOS 4.0, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Sync Mode (RS-232C Sync, Local Network Sync), Video Tag (4), Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting, Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, Crestron Connected®(Network based control ), PM Mode, Wake on LAN, HDMI-CEC( Compatibility may differ by equipment.), SI Server Setting, webRTC, Pro:Idiom
Environment Conditions
Operation Temperature: Operation Humidity
0°C to 40°C: 10 % to 80 %
Power
Power Supply: Power Type
AC 100 - 240 V ~, 50 / 60 Hz: Built-In Power
Power Consumption
Typ./Max: BTU (British Thermal Unit)
309 W / 318 W (Based on 8 color bar): 1,054 BTU/Hr (Typ.), 1,085 BTU/Hr (Max.)
Sound
Speaker: No
Certification
Safety: CB / NRTL
EMC: FCC Class "A" / CE / KC
ErP: Yes (EU Only)
Media Player Compatibility
OPS type compatible: OPS Power Built In
No: No
Software Compatibility
SuperSign CMS: Yes
SuperSign Control / Control+: Yes
SuperSign WB: Yes
SuperSign Media Editor: Yes
Signage365Care: Yes (The availability can differ by region.)
Accessory
Basic: Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS232C Gender, FFC Cables (220 mm × 4 ea for Connection Between Panel and Signage Box), DP Cable (2 M), RS232 Cable (4p-4p, 1.5 M), LC Cable (VLC, 3 M), Tape (4 ea for Cabling), Screw (M3 × L4.5, 30 ea / M3 × L5.5, 50 ea), Shield Cover Ass'y, Tiling Set Fixer 6 ea, Flex Bar 2 ea
