Panel
Screen Size 55"
Panel Technology OLED
Native Resolution 1,920 x 1,080 (FHD)
Brightness 150/400 nit (APL 100% / 25%)
Contrast Ratio 150,000 : 1
Color gamut BT709 120%
Viewing Angle (H x V) 178 × 178
Color Depth 10 bit (R), 1.07 Billion Colors
Response Time 1 ms (G to G) , 8 ms (MPRT)
Surface Treatment (Haze) Hard Coating (2 H)
Reflectance Typ. 1.2%
Operation Hours (Hours / Day) 18 / 7 (Moving Content Only)
Portrait / Landscape Yes / Yes
Connectivity
Input HDMI (HDCP 1.4), DP (HDCP 1.3), USB 2.0 Type A (2)
Output DP, Audio
External Control RS232C In / Out (w/ IR Out), RJ45 (LAN) In / Out, IR In (External IR Receiver)
Mechanical Specification
Bezel Color Black
Bezel Width (T / R / L / B) 0.6 / 6.7 / 6.7 / 0.6 mm (Off Bezel)
5.0 / 7.6 / 7.6 / 10.6 mm (On Bezel)
Weight (Head) 5.8 kg
(Signage Box) 3.5 kg
Monitor Dimension (W × H × D) 1,224.9 × 696.2 × 38.0 mm (Head, w/ Pemnut)
1,224.9 × 696.2 × 12.4 mm (Head, w/o Pemnut)
(Signage Box) 413 × 353 × 57.3 mm
Monitor Dimensions with Stand (W × H × D) No
VESA™ Standard Mount Interface No
Feature
Key Feature Internal Memory (16 GB), Temperature Sensor, FAN, webOS 4.0, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Sync Mode (RS-232C Sync, Local Network Sync), Video Tag (4), Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting, Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, Crestron Connected® (Network based control), Power (PM Mode, Wake on LAN), HDMI-CEC (Compatibility may differ by equipment.), SI Server Setting, Pro:Idiom
Environment Conditions
Operation Temperature 0°C to 40°C
Operation Humidity 10% to 80%
Power
Power Supply AC 100-240 V ~, 50/60 Hz
Power Type Built-In Power
Power Consumption
Typ./Max. 309 W / 318 W
BTU (British Thermal Unit) 1,054 BTU/Hr (Typ.), 1,085 BTU/Hr (Max.)
