55" Class (54.64" measured diagonally)
55XE3C
PANEL
Screen Size
Panel Technology
Aspect Ratio
Native Resolution
Contrast Ratio
Viewing Angle (HxV)
Surface Treatment
QWP Polarizer (FPR Film)
Local dimming
Life Time
Orientation
55" Class (54.64" measured diagonal)
IPS
16:9
1,920 x 1,080 (FHD), M+
1,000:1
178 x 178
Anti-refl ection treatment of the front polarizer (Refl ectance< 2.5%)
Yes
55" 160 Block
50,000 Hours
Portrait & Landscape
CONNECTIVITY
Input
Output
External Control
HDMI, DP, DVI-D, Audio
DP, External Speaker Out
RS232C, RJ45, USB 3.0, SD Card
PHYSICAL SPECIFICATION
Front glass
Bezel Color
Bezel Width
Monitor Dimension (W x H x D)
Weight (Head)
Monitor with Optional Stand Dimensions (W x H x D)
Weight (Head+Stand)
Packing Dimensions (W x H x D)
7.5 mm (AR, Front Safety Vandal Glass)
Medium Texture Black (Common color)
66.4 mm (T/B), 31.0 mm (L/R)
745.3 x 1,345.4 x 160.0 mm
70 kg
745 x 542 x 420 mm
100.5 kg
1,027 x 1,491 x 309 mm
SPECIAL FEATURES
Yes
Temperature Sensor, Auto-Brightness Sensor, Pixel Sensor, Cooling Fan, ISM Method, DPM Select, Energy Saving, Smart Energy Saving, File Play with USB, Internal Memory (8 GB), Easy Brightness Control, Content Scheduling, Fail over
ENVIRONMENT CONDITIONS
Operation Tempature
Operation Humidity
Direct Sunlight
Dust / Water Proofing
-30 °C to 50 °C
10 % ~ 100% (TBD)
Yes
IP 56
POWER
Power Supply
Power Type
Power Consumption Typ./Max
Power Consumption Smart Energy Saving
100 -240V~, 50/60Hz
Built-In Power
Typ. 350 W / Max. 500 W
178 W
STANDARD (CERTIFICATION)
Safety
EMC
ErP / Energy Star
UL / cUL / CB
FCC Class "A" / CE / KCC
No / No
SOFTWARE COMPATIBILITY
SuperSign W/Lite
SuperSign C
Yes
Yes
ACCESSORIES
Accessories
Optional Accessories
Remote controller, Manual, QSG, Regulation book, Phone to RS232C Gender, USB cable, HDMI cable
Media player (driven by customer), Enclosure Stand
MEDIA PLAYER COMPATIBILITY
OPS type compatible
External Media player Attachable
No
No
