Display
Panel Technology IPS Viewable Image Size 65 "
Aspect Ratio 16:9 Screen Resolution 3840x2160
Supported Resolutions DIsplayPort: V1.2 (HDCP 1.3/2.2)VGA60, SVGA60, XGA60, SXGA60, UXGA60, WUXGA60, 1920 x 1080 (60Hz), 1080p, 1080i, 720p@50 Hz/60 Hz, 576p@50 Hz, 480p@60 Hz, 3840x2160 (24 Hz/25 Hz/30 Hz/50 Hz/60 Hz), 4096x2160 (24 Hz/25 Hz/30 Hz/50 Hz/60 Hz)HDMI (HDCP 1.4/2.2)VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60, WUXGA60, 1920x1080 (60 Hz), 1080p, 1080i, 720p@50 Hz/60 Hz, 576p@50 Hz, 480p@60 Hz, 576i@50 Hz, 480i@60 Hz, 3840x2160 (24 Hz/25 Hz/30 Hz/50 Hz (MODE2)/60 Hz (MODE2)),4096x2160 (24 Hz/25 Hz/30 Hz/50 Hz (MODE2)/60 Hz (MODE2)) Pixel Pitch 0.37 mm
Pixels Per Inch 68 PPI Backlight Type LED Direct-lit
Brightness (typical) 500 cd/m2 Contrast Ratio (typical) ≥8,000:1 (Out of the box conditions, local dimming ON)
Viewing Angle (typical) 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10 Response Time (Gray to Gray) 8 ms
Refresh Rate 60Hz Active Screen Area 56.2 x 31.6 in. / 1428.5 x 803.5mm
Orientation Landscape/Portrait Dimming Capability Local Dimming Capable
Displayable Colors More than 1.07 billion (8-bit+FRC) Color Temperature (Max) (°K) 10000K
Color Temperature (Min) (°K) 2600K Gamma (Typical) Native, 2.2, 2.4, S-Gamma, DICOM, Programmable1, Programmable2, Programmable3
Synchronization Range
Horizontal (Analog/Digital) Digital: 26.0 - 135.0kHz Vertical Digital: 23.0 - 86.0Hz
Input Signal
Video Digital TMDS / DisplayPort
Signal Compatibility/Connectivity
PC Signal Compatibility Yes Macintosh Signal Compatibility Yes
Video Digital TMDS / DisplayPort External Control LAN and RS232 In - Full external control capabilities
Input Terminals
Digital:
HDMI (2.0 x 2 with HDCP), DisplayPort (1.2 with HDCP)
Audio:
Audio Mini-Jack, DisplayPort Audio, HDMI Audio
External Control:
RS-232C, LAN (100Mb), 3.5mm Mini-Jack (IR Remote)
Data:
USB 2.0 (Media Player)
Output Terminals
Audio:
3.5mm Mini-Jack
Power Consumption (typical)
On 165W ECO Mode Standby <0.5W
Network Standby 2W Power Consumption (max) 165W (Max Brightness), 320W (Brightness Max, SDM Max, Volume Max)
Input Current 3.4A @ 100V
1.6A @ 240V
Physical Specifications
Bezel Width (Left/Right, Top/Bottom) 0.59 in./0.59 in., 0.59 in./0.59 in. : 14.9 mm/14.9 mm, 14.9 mm/14.9 mm Dimensions (WxHxD)
Without stand:
57.6 x 33 x 2.7 in. / 1462.3 x 837.3 x 68.1 mm
Shipping:
68.4 x 40.7 x 11.0 in. / 1736.0 x 1033.0 x 280.0mm
Weight
Net Weight (without stand):
64.8 lbs. / 29.4 kg.
Shipping:
91.9 lbs. / 41.7kg
VESA Hole Configuration 400 x 400mm (M8 x 4-hole)
Environmental Conditions
Operating Temperature 32-104°F / 0-40°C Operating Humidity 20 - 80%
Operating Altitude 9843 ft. / 3000m Storage Temperature -4-140°F / -20-60°C
Storage Humidity 10-80% Storage Altitude 40,000 ft. / 12,192m
Environmental Compliance
ENERGYSTAR Energy Star 8.0
Limited Warranty (parts & labor)
3 years Advanced Exchange
Additional Features
AMX Support
Automated Email Alert Function
ARC Support through HDMI
Crestron Roomview Support (FW Update)
Display Browser Control
Display Wall Calibrator Compatible
HDR Support (PQ, HLG, HDR10)
Key Guide
NaViSet Administrator 2 Compatible
OSD Rotation for Portrait Orientation
Accepts Intel(R) SDM-S or SDM-L
PJ Link Support
Power USB Port (5V/2A)
Raspberry Pi Compute Module 4 Compatible
Removeable Logo Ornament
Real Time Clock
Local Dimming
TileMatrix
SNMP
Consumer Electronics Control (CEC)
Integrated USB Media Player
Integrated Temperature sensor
Full Input Detect Functionality
Programmable Gamma
Energy Star 8.0
Scheduler Function
Off Timer
Vacation Switch

Accessories
Included
3m Power cord
2.0m HDMI cable
Wireless remote control
Batteries
Optional
Wall Mount (WMK-3298T)
IR/Human Sensor Accessory (KT-RC3)
Table Top Stand (ST-43M)
SDM Tuner (DS1-TM01)
Cooling Method
Integrated Temperature Sensor and Cooling Fan for SDM
