Parametry:

Product Specifications

Display

Aspect Ratio: Maximum Resolution
16x10: Up to 4K@30Hz (3840x2160) with Advanced AccuBlend, Pixel clock frequency:less than 300MHz
Native Resolution: Contrast Ratio (typical)
WXGA 1280x800: 16,000:1
Synchronization Range

Horizontal (Analog/Digital)

15-100kHz (RGB: 24kHz or over)

Vertical

50-120Hz

Signal Compatibility/Connectivity

Supported Video Standards

NTSC3.58/NTSC4.43/PAL/PAL-N/PAL-M/PAL-60/SECAM

SD/HD Video Signal Compatibility

480i, 480p, 576i, 576p, 720p, 1080i, 1080p

PC Signal Compatibility

VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA

Macintosh Signal Compatibility

Yes

External Control

RS-232 (D-Sub 9pin), IR, LAN

Input Terminals

RGB1(analog):

VGA 15pin D-sub

RGB2(digital):

HDMI w/ HDCP

RGB3(digital):

HDMI w/ HDCP

Video 1:

RCA

Audio 1:

Stereo Mini Jack

Audio 2:

RCA (L/R)

Output Terminals

Audio:

Stero Mini Jack

Audioout:

Yes (variable)

Monitor Out:

VGA 15pin D-sub

Power Consumption (typical)

On

288W

Input Current

3.3-1.3A

Power Requirements

100-240V AC, 50/60 Hz

Physical Specifications

Dimensions (WxHxD)

Product:

13.6 x 10.3 x 4.1 in. (345 x 261 x 104.6 mm)

Shipping:

17.7 x 15.4 x 7.8 in. (450 x 390 x 200 mm)

Weight

Net Weight:

7.1 lbs. (3.2 kg)

Shipping:

10.4 lbs. (4.7 kg)

Environmental Conditions

Operating Temperature

41-104°F / 5-40°C

Storage

-14-122°F / -10-50°C

Limited Warranty (parts & labor)

Registered owners receive a 3-year parts and labor warranty including InstaCare next business day exchange. One year on lamp.:
Additional Features

Keystone correction
Wireless LAN (Optional)
USB Viewer
Cornerstone
Auto power on
ECO Mode technology
Variable audio out
Carbon savings meter
Virtual Remote
Sleep timer
Built-in wall color correction
Advanced AccuBlend
AutoSense
MultiPresenter

Optical

Display Technology

0.64" LCD

Light Output(Lumens)

3800 normal

Lamp Type

225W AC

Lamp Life (up to)

10,000 hours normal / 15,000 hours eco

Screen Size (diagonal)

30 - 300 in. / 0.76 - 7.62m

Throw Ratio

1.4 - 1.6:1

Projection Distance

2.9 - 35.9 ft. / 0.9 - 10.9 m

Projector Angle

0 - 9° tele / 0 - 10° wide (at 60")

Lens

Zoom:

1.2

Focus:

Manual

F number, fnumber:

F:1.6~1.76 /f=19.158~23.018mm

Keystone Correction

+/- 20° horizontal, +/- 30° vertical

Mechanical

Installation Orientation

Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear

Fan Noise

37 dB ECO mode off / 34 dB Normal ECO / 29 dB ECO mode

Regulations

USA: UL (UL60950-1/UL62368-1) FCC Part15 Class B, Canada: C-UL (CSA60950-1) ICES-003 Class B, NOM

Light Output

3800normal:
Fan Noise

37 dB ECO mode off / 34 dB Normal ECO / 29 dB ECO mode:
Regulations

USA: UL (UL60950-1/UL62368-1) FCC Part15 Class B, Canada: C-UL (CSA60950-1) ICES-003 Class B, NOM:
Hide Full Specifications

Technologies

16W Audio

provides the volume needed for large rooms

4K Ready

Designed with the exhibitor in mind, this digital cinema projector is fully upgradable to 4K technology when available, making the transition a seamless and cost-effective solution.

Advanced AccuBlend™

Ensures detailed images when non-native resolution sources are connected to the projector.

Auto Power On

Powers on the projector as soon as it is plugged into a power outlet.

AutoSense™

Intuitively syncs the projector with most computer signals and features one-touch image optimization.

Built-In Closed Captioning

Enables decoding and display of text information from a video.

Built-in Wall Color Correction

Presets provide for adaptive color tone correction to display properly on non-white surfaces.

Carbon Savings Meter

Calculates the positive effects of operating the projector in ECO Mode, which is encouraged by an optional message at startup. A green ECO Mode button on the remote control makes the switch easy.

Computer-Free Presentations

Insert a USB drive or compact flash memory card directly into the projector and change images using the wireless remote control provided with the projector.

Cornerstone Correction

Allows for horizontal, vertical and diagonal image correction for aligned images even when the projector is set up at an angle to the screen.

Crestron Roomview

Provides unified management, including the ability to switch the power on and off for multiple projectors connected to a network.

Direct Power Off

Protects the lamp when the projector is accidentally unplugged or the power strip is switched off. Enables the fan to continue running until the lamp is properly cooled down. Internal sensors monitor lamp temperature and prevent the lamp from powering on.

Discreet Source Keys

Projector and remote feature direct access buttons for source selection.

Dual Computer Inputs

Ensures quick switching between presentations.

Dual HDMI inputs (with HDCP)

Ensure quick switching between presentations and allows for simultaneous digital connections of high-definition sources, such as Blu-ray players, cable boxes, satellite receivers and computers

ECO Mode™

Extends lamp life, lowers audible noise and reduces total cost of ownership.

Geometric Correction

Allows you to project on spheres, cylinders, corner angles and more.

Power Management

Enables projector to automatically turn off when an incoming signal is not detected from any of the inputs.

Quick Startup and Quick Power-Off

Allows users to begin presenting within 3 to 4 seconds and allows immediate power off with no cooling required after shutdown to ensure efficient energy usage.

Remote Diagnostics

Enables the user to monitor and make adjustments to the projector from a remote location.

USB Viewer

Permits playback (without a PC) of presentations or display images stored as JPG files from a USB flash drive.

Variable Audio Out

Adjusts the volume of an external speaker system using the projector's remote control.

Wired Network Connection

Integrated RJ45 connection for quick connection to the LAN (10/100 base-T capability).

Wireless LAN (Optional)

Allows you to transmit images from a PC wirelessly to the projector, eliminating the need for traditional cumbersome cables.
