TECHNICAL SPECIFICATIONS
Display 1 x 1.4 cm (0.55") DDR DMD Chip (Aspect Ratio 4:3)
Lamp 180 W DC
Lamp Life [hrs] 3500 (4000 Eco Mode)
Brightness 1 2000 ANSI Lumens
Contrast Ratio 1 2000:1
Diagonal: min. / max. [cm] 70 / 769
Projection Distance [m] 1.2 – 12
Projection Factor 1.95 – 2.15 : 1
Frequency Horizontal: 31.35–68.7 kHz; Vertical: 56 – 85 Hz
Native Resolution 800 x 600 (SVGA)
Supported Resolutions 1280 x 1024; 1152 x 870 (Mac 21"); 640 x 480 (VGA/Mac 13"); 1024 x 768 (XGA) compressed
ComputerAnalog Input: 1 x Mini D-sub 15-pin, compatible to component (YPbPr);
Output: 1 x Mini D-sub 15 pin
Video Input: 1 x RCA
S-Video Input: 1 x Mini DIN 4-pin
Audio Input: 1 x 3.5 mm Stereo Mini Jack
Video Signals PAL / PAL60 / NTSC / SECAM / NTSC 4.43 / PAL-N / PAL-M
Audio Functions [W] 1 x 2 (mono)
Zoom / Focus Adjustment Manual / Manual
Benefits 6-segment Colour Wheel; Long Life Lamp; Manual, vertical Keystone Correction (V= ±40°); Plug&Play;
Source Select + Lock Function
Remote Control Audio Control; Freeze-function; Keystone Correction; Magnify-function; Mute-function; Source Select
Dimensions (W x H x D) [mm] 272 x 80 x 199 (without lens and feet)
Weight [kg] 2.3
Power Supply 100-240 V AC; 50 - 60 Hz
Power Consumption [W] 228 max.; 190 Eco Mode; 7 Stand-by Mode
Fan Noise [dB (A)] 33
Safety and Ergonomics CE; TÜV GS; RoHS
Warranty Projector: 3 years pan-European Premium Service (Exchange Service); Lamp: 6 Months, max. 1000 Hrs
Shipping Contents Projector; IR remote control; Mini D-SUB Signal Cable (1.8 m); Power Cord (1.8 m); Users Manual on CDROM; Quick Setup Guide; Lens Cap
Optional Accessories Ceiling Mount Kit (NP09CM); Lamp (NP10LP)
