Display 1 x 1.4 cm (0.55") DDR DMD Chip (Aspect Ratio 4:3)
Lamp 220 W UHP AC (180 W UHP AC Eco Mode)
Lamp Life [hrs] 2000 (3000 Eco Mode)
Brightness 1 3000 ANSI Lumens (2400 ANSI Lumens Eco Mode)
Contrast Ratio 1 1600:1
Lens F= 2.2–2.34, f= 20.4–24.5 mm
Diagonal: min. / max. [cm] 84 (33") / 762 (300")
Projection Distance [m] 1.45 – 13.43
Projection Factor 1.8 – 2.16 : 1
Frequency Horizontal: 15–100 kHz (RGB: 24 kHz or more); Vertical: 50 – 85 Hz
Native Resolution 1024 x 768 (XGA)
Supported Resolutions 1920 x 1080 (HDTV 1080i@50/60Hz); 1600 x 1200 (UXGA); 1400 x 1050 (SXGA+); 1280 x 1024 (SXGA);
1152 x 900 (SUN); 1024 x 768 (XGA); 832 x 624 (Mac); 800 x 600 (SVGA); 640 x 480 (VGA/Mac); 1280 x
720 (HDTV 720p) compressed; NTSC 15.7 kHz; PAL15.6 kHz; SDTV 480p/576p
ComputerAnalog Input: 1 x Mini D-sub 15-pin, compatible to component (YPbPr)
Video Input: 1 x RCA
S-Video Input: 1 x Mini DIN 4-pin
PC Control Input: 1 x Mini DIN 8 pin (female)
Video Signals PAL / PAL60 / NTSC / SECAM / NTSC 4.43 / PAL-N / PAL-M
Zoom / Focus Adjustment Manual / Automatic/manual
Benefits Automatic Focus (1.5–5.5 m distance); Automatic Signal Detection; automatic, vertical Keystone Correction
(V= ±16°); Colour Management; IR Remote Control with Optional Mouse and Presentation Control; OffTimer; OSD with 20 languages (without help); Password Security System; Plug&Play; Quick-Start-/QuickPower-Off Function; Supports Windows Vista Network Functions; Wall Colour Correction
Remote Control Type RD-423E; Aspect Ratio; Automatic Picture Adjustment; Direct Source Select; Freeze-function; Helpfunction; Lamp Mode Control; Mute-function; Optional Presentation and Mouse Control; Page Control
Dimensions (W x H x D) [mm] 246 x 72 x 177 (without lens and feet)
Weight [kg] 1.6
Power Supply 200-240 V AC; 50 - 60 Hz
Power Consumption [W] 285 Normal Mode; 240 Eco Mode; 6 Stand-by Mode
Calorific Value max. 970 BTU (1 KWh= 3,412.14 British Thermal Unit)
Fan Noise [dB (A)] < 35 Eco Mode
Safety and Ergonomics CE; TÜV GS; RoHS
Warranty Projector: 3 years pan-European Premium Service (Exchange Service); Lamp: 6 Months, max. 1000 Hrs
Shipping Contents Projector; IR Remote Control (RD 423E); Mini D-SUB Signal Cable (1.8 m); Power Cord (3 m); Soft Case;
Users Manual on CD-ROM (7 Languages); Quick Setup Guide (6 Languages); Lens Cap
Optional Accessories Ceiling Mount Kit (NP02CM); Lamp (NP03LP); Mouse Receiver (NP01MR); YUV Cable (ADP-CV1)
1
Compliance with ISO21118-2005
