Display
Aspect Ratio 16x9 Native Resolution 1080p 1920x1080
Maximum Resolution WUXGA 1920 x 1200 Contrast Ratio (typical) 6000:1 with lamp control
Synchronization Range
Horizontal (Analog/Digital) 15-100 kHz/15-153 kHz Vertical 50-120 Hz/24-120 Hz
Signal Compatibility/Connectivity
Supported Video Standards NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM SD/HD Video Signal Compatibility 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
PC Signal Compatibility VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA Macintosh Signal Compatibility Yes
Sync Compatibility Separate Sync / Composite Sync / Sync on G External Control RS-232, IR, DDC/CI, USB, LAN
Input Terminals
RGB1(analog):
VGA 15-pin D-sub
RGB2(digital):
HDMI w/HDCP
RGB3(digital):
HDMI w/HDCP
RGB4(digital):
HDBaseT
Video 1:
RCA
Audio 1:
RCA
Audio 2:
1/8 in. stereo
Output Terminals
Audio Out:
1/8 in. stereo (Variable audio out)
Power Consumption (typical)
On 426W / 288W / 2.7W / 0.26W Input Current 4.9-2.0A
Power Requirements 100-240V AC, 50/60 Hz
Physical Specifications
Dimensions (WxHxD)
Product:
14.3 x 11.9 x 5.0 in. / 362 x 302 x 128mm
Weight
Net Weight:
12.1 lbs. / 5.5 kg
Environmental Conditions
Operating Temperature 41-104°F / 5-40°C Storage 14-122°F / -10-50°C
Limited Warranty (parts & labor)
3 years (excluding consumables). First year Instacare Service.
Additional Features
Manual keystone correction
Wireless LAN
USB Viewer
Auto power on
ECO Mode technology
Closed captioning
Variable audio out
Carbon savings meter
Virtual Remote
Sleep timer
Built-in wall color correction
Advanced AccuBlend
AutoSense

Optical
Display Technology DLP (0.65" DMD) Lamp Type 335W AC
Light Output(Lumens) 4500 normal Light Source Life 5,000 hours
Screen Size (diagonal) 30 to 300 in. / 0.76 to 7.6m Throw Ratio 1.24 to 2.1
Projection Distance 2.6 to 46.6 ft. / 0.8 to 14.2m Projector Angle 7.5 to 7.7° tele / 12.8 to 13.1° wide
Lens
Zoom:
1 to 1.7
Focus:
Manual
F number, fnumber:
F=2.0, f=18.2 to 31.1mm
Keystone Correction +/- 25° horizontal, +/- 30° vertical
Mechanical
Installation Orientation Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear Fan Noise 39 dB normal / 31 dB eco
Regulations USA UL 60950-1 / FCC Part15 Class B, Canada CSA 60950-1 / ICES-003 Class B, NOM
