Display
Aspect Ratio 16x10 Native Resolution WUXGA 1920x1200
Maximum Resolution WUXGA 1920 x 1200 Contrast Ratio (typical) 18,000:1
Synchronization Range
Horizontal (Analog/Digital) 15-100 kHz (RGB: 24 kHz or over) Vertical 50-120 Hz
Signal Compatibility/Connectivity
Supported Video Standards NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM SD/HD Video Signal Compatibility 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
PC Signal Compatibility VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA Macintosh Signal Compatibility Yes
Sync Compatibility Separate Sync / Composite Sync / Sync on G External Control RS-232, IR, DDC/CI, USB, LAN
Input Terminals
RGB1(analog):
VGA 15-pin D-sub
RGB2(digital):
HDMI w/HDCP
RGB3(digital):
HDMI w/HDCP
RGB4(digital):
HDBaseT
Video 1:
RCA
Audio 1:
RCA
Audio 2:
Mini stereo
Output Terminals
Audio Out:
1/8 in. stereo (Variable audio out)
Power Consumption (typical)
On 424W / 286W / 2.0W / 0.14W Input Current 4.7-1.9A
Power Requirements 100-240V AC, 50/60 Hz
Physical Specifications
Dimensions (WxHxD)
Product:
16.5 x 5.6 x 13.0 in. (420 x 141 x 329 mm)
Shipping:
18.9 x 9.2 x 15.4 in. (480 x 234 x 391 mm)
Weight
Net Weight:
10.6 lbs. / 4.8 kg
Shipping:
14.4 lbs. / 6.5 kg
Environmental Conditions
Operating Temperature 41-104°F / 5-40°C Storage 14-122°F / -10-50°C
Limited Warranty (parts & labor)
Registered owners receive a 3 year parts and labor warranty including InstaCare next business day exchange. The lamp is covered for one year or 1,000 hours, whichever comes first.
Additional Features
Manual keystone correction
Wireless LAN (control only)
USB Viewer
Auto power on
ECO Mode technology
Closed captioning
Variable audio out
Carbon savings meter
Virtual Remote
Sleep timer
Built-in wall color correction
Advanced AccuBlend
AutoSense

Optical
Display Technology 0.64" LCD Lamp Type 330W AC
Light Output(Lumens) 5,000 (Center)
4700 (Eco Off)
4050 (Normal Eco)
3050 (Eco) Light Source Life 4000 hours (Eco Off) / 6000 hours (Normal Eco) / 8000 hours (Eco)
Screen Size (diagonal) 30 to 300 in. / 0.76 to 7.6m Throw Ratio 1.2-2.0:1
Projection Distance 2.6 to 42.3 ft. / 0.8 to 12.9m Projector Angle 0 to 10.0° tele / 0 to 16.0° wide
Lens
Zoom:
1 to 1.6
Focus:
Manual
F number, fnumber:
F=1.5 to 2.08, f=17.2 to 27.7mm
Keystone Correction Manual +/- 20° horizontal, +/- 30° vertical
Mechanical
Installation Orientation Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear Fan Noise 37 dB normal / 34 dB eco
Regulations USA UL 60950-1 / FCC Part15 Class B, Canada CSA 60950-1 / ICES-003 Class B, NOM
