Display
Aspect Ratio 16x10 Native Resolution WXGA 1280x800
Maximum Resolution 4K 4096 x 2160 Contrast Ratio (typical) 5000:1 with auto iris
Synchronization Range
Horizontal (Analog/Digital) Analog: 15-100kHz, Digital: 15-153kHz Vertical Analog: 48-120Hz, Digital: 24-120Hz
Signal Compatibility/Connectivity
Supported Video Standards NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM SD/HD Video Signal Compatibility 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
PC Signal Compatibility VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA, WQXGA, 4K Macintosh Signal Compatibility Yes
Sync Compatibility Separate Sync / Composite Sync / Sync on G External Control RS-232, IR, DDC/CI, USB
Input Terminals
RGB1(analog):
VGA 15-pin D-sub
RGB2(analog):
5-BNC
RGB3(digital):
HDMI w/HDCP
RGB4(digital):
HDMI w/HDCP
RGB5(digital):
DisplayPort w/HDCP
Audio 1:
Mini stereo
Audio 2:
Mini stereo
Output Terminals
Audio Out:
1/8 in. stereo (Variable audio out)
Power Consumption (typical)
On 463W / 377W / 4.7W / 0.11W Input Current 5.1-2.1A
Power Requirements 100-240V AC, 50/60 Hz
Physical Specifications
Dimensions (WxHxD)
Product:
19.7 x 14.4 x 6.5 in. / 499 x 366 x 164mm
Weight
Net Weight:
18.5 lbs. / 8.4 kg
Environmental Conditions
Operating Temperature 41-104°F / 5-40°C Storage -14-122°F / -10-50°C
Limited Warranty (parts & labor)
3 years. Lamp warranty is 1 year or 500 hours, whichever comes first.
Additional Features
Automatic keystone correction
Optional Wireless LAN
Active Lens Cover
USB Viewer
Cornerstone
Geometric Correction
4000 hour Filter Life
Auto power on
ECO Mode technology
Closed captioning
Variable audio out
Carbon savings meter
Virtual Remote
Sleep timer
Quick power-off
Built-in wall color correction
Advanced AccuBlend
AutoSense

Optical
Display Technology 0.75" LCD w/ MLA Lamp Type 330W AC
Light Output(Lumens) 5700 normal Light Source Life 3000 hours normal / 4000 hours eco
Screen Size (diagonal) 40 to 500 in. / 1.02 to 12.7m Throw Ratio 1.5 to 3.02
Projection Distance 2.5 to 68.5 ft. / 0.74 to 20.9m Projector Angle 10.3 to 10.8° tele / 13.7 to 14.5° wide
Lens
Zoom:
1 to 2.01
Focus:
Manual
F number, fnumber:
F=1.7 to 2.37, f=24.4 to 48.6mm
Keystone Correction +/- 40° horizontal, +/- 40° vertical
Mechanical
Installation Orientation Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear Fan Noise 39 dB normal / 33 dB eco
Regulations USA UL 1950 FCC Class B, Canada CSA 950 (C-UL), NOM Optional Lenses NP11FL, NP12ZL, NP13ZL, NP14ZL, NP15ZL, NP30ZL
