Projection Technology 3LCD Technology
Native Resolution
1280 x 800 (WXGA)
Aspect Ratio 16:10
Contrast Ratio 1 500000:1
Brightness 1 4500 ANSI Lumen
Lamp Laser Light Source
Light Source Life [hrs] 20000 2
Lens F= 1.5–2.1, f= 17.2–27.6 mm
Lens shift H:±29, V:+60,-0
Keystone correction +/- 30° manual horizontal / +/- 30° manual vertical
Projection Factor 1.23 – 2 : 1
Projection Distance [m] 0.8 – 13.5
Screen Size (diagonal) [cm] / [inch] Maximum: 762 / 300"; Minimum: 76.2 / 30"
Zoom Manual; x1.6
Focus Adjustment Manual
Supported Resolutions
1920x1200 (Maximum resolution of analog input);
3840 x 2160 (Maximum resolution of digital input);
3840x2160 @ 30hz digital
Connectivity
RGB (analog) Input: 1 x Mini D-sub 15 pin
Digital Input: 2 x HDMI™ supporting HDCP
Audio Input: 1 x 3.5 mm Stereo Mini Jack for Computer analog; 2 x HDMI audio
Output: 1 x 3.5 mm Stereo Mini Jack (variable)
Control Input: 1 x D-Sub 9 pin (RS-232) (male)
LAN 1 x RJ45; Optional WLAN
USB 1 x Type B (for Service); 1x Type A (USB 2.0 high speed) with 2.0A Power Supply
Video Signals NTSC 3.58; NTSC 4.43; PAL; PAL-M; PAL-N; PAL60; SECAM
Remote Control
Remote Control Aspect Ratio; Audio Control; Auto Adjust; Eco Mode Control; Freeze-function; Help-function; ID set; Keystone Correction; Magnify-function; Page (up, down); Picture Adjust; Picture Mute; Power (On-OFF); Presentation and Mouse Control; Select (up, down, left, right); Source Select
Electrical
Power Supply 100-240 V AC; 50 - 60 Hz
Power Consumption [W] 308 (Normal) / 222 (Eco) / 1.8 (Network Stand-by) / 0.3 (Stand-by)
Mechanical
Dimensions (W x H x D) [mm] 480 x 122 x 407 (without lens and feet)
Weight [kg] 9.7
Fan Noise [dB (A)] 22 / 24 / 27 (ECO / Normal / High Bright)
Colour Versions White
Environmental Conditions
Operating Temperature [°C] 5 to 40
Operating Humidity [%] 20 to 80
Storage Temperature [°C] -10 to 50
Storage Humidity [%] 20 to 80
Ergonomics
Safety and Ergonomics CE; EAC; ErP; RoHS; TUEV Type Approved; TüV GS
Speakers [W] 1 x 20 (mono)
Additional Features
Special Characteristics Auto Power ON/OFF; Carbon Savings Meter; Constant Brightness Mode; Control ID Function; DICOM simulation; Direct Power-Off Function; Free Tilt; Help Function; HTTP Browser Control; Kensington security slot; Keypad Lock; Light Source Adjustment; Magnify; Mouse Control with USB Display; MultiPresenter Function; NaViSet Administrator 2; Optional User Logo; OSD with 30 languages; Password Security System; Plug&Play W-LAN Option; Portrait Setting; Quick Start; Source Select with Beep Function; Test Pattern; Unique Power Saving Functions; USB Viewer; Virtual Remote for direct PC control
Green Features
Ecological Materials Downloadable manuals; ECO packaging
Ecological Standards ErP compliant; RoHs compliant
Warranty
Projectors 3 years pan-European service
Light Source 3 years or 10000h (whatever comes first)
Shipping Content
Shipping Contents 2x AAA Batteries; IR Remote Control (477E); Mini D-SUB Signal Cable (1.8 m); Power Cord (1.8 m); Projector; Quick Setup Guide; Security Sticker; Users Manual; Utility software
Optional Accessories
Optional Accessories Universal Ceiling Mounts (PJ01UCM, PJ02UCMPF); Wireless LAN module (NP05LM2; NP05LM4; NP05LM5)
1 Compliance with ISO21118-2012

2 50% of initial brightness at the end of specified laser life time at 25 degree ambient temperature.

* This product has been equipped with a laser module and is classified as Class1 of IEC60825-1 Ed3 2014 and is classified as RG2 of IEC62471-5 Ed1 2015.
DO NOT LOOK DIRECTLY INTO THE BEAM.
