Display 1 x 1,65 cm (0,65") 2 x LVDS DMD (kuvasuhde 16:10)
Native Resolution 1280 x 800 (WXGA)
Brightness 1 2600 ANSI Lumens
Contrast Ratio 1 2000:1
Lamp 230 W AC
Lamp Life [hrs] 2500 (4000 Eco Mode)
Lens F= 2,71, f= 4,42 mm
Projection Factor 0,3 : 1
Projection Angle [°] 55,3
Projection Distance [m] 0,152 – 0,319
Screen Size (diagonal) [cm] Minimum: 196 / 77"; Maximum: 254 / 100"
Zoom Manual; Digital Zoom
Supported Resolutions VGA; SVGA; XGA; WXGA; SXGA; SXGA+; UXGA
Frequency Horizontal: 15–91,1 kHz (RGB: 31,35 kHz– 91,1 kHz); Vertikaalisesti:
50 – 85 Hz (120 Hz: vain 3D-signaalille)
CONNECTIVITY
RGB (analog) Input: 2 x Mini D-sub 15-pin, compatible to component (YPbPr);
Output: 1 x Mini D-sub 15 pin
Video Input: 1 x RCA
HDMI® Input: 1 x HDMI® (Deep Color, Lip sync) with HDCP
S-Video Input: 1 x Mini DIN 4-pin
Audio Input: 2 x 3.5 mm Stereo Mini Jack; Input: 1 x RCA Stereo for Video
and S-Video; Output: 1 x 3.5 mm Stereo Mini Jack
PC Control Input: 1 x D-Sub 9 pin (RS-232) (male)
LAN 1 x RJ45
Video Signals PAL; PAL60; NTSC; SECAM; NTSC 4.43; PAL-N; PAL-M
REMOTE CONTROL
Remote Control Source Select; Keystone Correction; Aspect Ratio; Mute-function;
Volume; Picture Adjust; Menu; Power (On-OFF); Jäädytys; Apu-Ecomode; Digitaalinen zoom; Esitys- ja hiiriohjaus; AV-mykistys; IDasetus
ELECTRICAL
Power Supply 100-240 V AC; 50 - 60 Hz
Power Consumption [W] 300 (Normal) / 245 (Eco) / 2 (Network Stand-by) / 0,5 (Stand-by)
MECHANICAL
Dimensions (W x H x D) [mm] 427 x 200 x 406 (without lens and feet)
Weight [kg] 6,5
Fan Noise [dB (A)] 29 / 33 (Eco / Normal)
ENVIRONMENTAL CONDITIONS
Operating Temperature [°C] 5 to 35
Operating Humidity [%] 20 to 80
Storage Temperature [°C] -10 to 50
Storage Humidity [%] 20 to 80
OPTIONAL ACCESSORIES
Optional Accessories Lamp (NP19LP); Motorized Height Adjustable Wall Mount NP01HW;
Mobile Motorized Wall Mount NP01HM; Manual Height Adjustable
Wall Mount NP01HWM
ERGONOMICS
Safety and Ergonomics CE; TÜV GS; ErP; RoHS
Speakers [W] 1 x 10 (mono)
WARRANTY
Projectors 3 years pan-European service
Lamp 6 months, max. 1000 hrs
SHIPPING CONTENT
Shipping Contents Projector; IR Remote Control with Batteries; Power Cord (3,0 m);
VGA-kaapeli (3,0 m); Seinäasennussarja NP01WK; Users Manual
on CD-ROM; Quick Setup Guide
1Compliance with ISO21118-2005
