Display 3 x 1,6 cm (0,63") p-Si LCD Panel with MLA
Lamp 210 W (172 W Eco Mode)
Lamp Life [hrs] 2500 (3500 Eco Mode)
Brightness 1 3000 ANSI Lumens (2400 ANSI Lumens Eco Mode)
Contrast Ratio 1 500:1
Lens F= 1,7–2,07, f= 18,9–22,7 mm
Diagonal: min. / max. [cm] 53 / 762
Projection Distance [m] 0,7 – 11,1
Projection Factor 1,5 – 1,8 : 1
Frequency Horizontal: 15–100 kHz (RGB: 24 kHz– 100 kHz); Vertical: 50 – 120 Hz
Native Resolution 1024 x 768 (XGA)
Supported Resolutions 1920 x 1080 (HDTV 1080i/60, HDTV 1080i/50); 1600 x 1200 (UXGA); 1280 x 1024 (SXGA); 1280 x 1024
(Mac 23"); 1280 x 720 (HDTV 720p); 1152 x 870 (Mac 21"); 832 x 624 (Mac 16"); 800 x 600 (SVGA);
720 x 576 (DVD progressive); 720 x 480 (DVD progressive); 720 x 480 (SDTV 480p); 640 x 480 (VGA/Mac
13"); 1024 x 768 (XGA) compressed
ComputerAnalog Input: 1 x Mini D-sub 15-pin, compatible to component (YPbPr);
Output: 1 x Mini D-sub 15 pin
DVI Input: 1 x DVI-I with HDCP, shared with DVI analog (DVI-VGA Adapter)
Video Input: 1 x RCA
S-Video Input: 1 x Mini DIN 4-pin
Audio Input: 1 x RCA Stereo for Video and S-Video; Input: 1 x 3.5 mm Stereo Mini Jack for Computer analog;
Output: 1 x 3.5 mm Stereo Mini Jack (variable)
PC Control Input: 1 x Mini DIN 8 pin (female)
Video Signals PAL / PAL60 / NTSC / SECAM / NTSC 4.43 / PAL-N / PAL-M
Audio Functions [W] 1 x 5 (mono)
Zoom / Focus Adjustment Manual / Manual
Benefits Automatic and manual vertical Keystone Correction (V= ±30°); Colour Management; Help Function; Manual
Wall Color Correction; Off-Timer; Optional User Logo; OSD with 21 languages; Password Security System;
Plug&Play; Quick-Start-/Quick-Power-Off Function; RS-232 Control; Short Throw Lens; Source Select with
Beep Function; Supports Windows Vista Network Functions
Remote Control Type RD-427E; Aspect Ratio; Audio Control; Auto Adjust; Freeze-function; Lamp Mode Control; Magnifyfunction; Optional Presentation and Mouse Control; Page (up, down); Picture Adjust; Picture Mute; Power
(On-OFF); Select (up, down, left, right); Source Select
Dimensions (W x H x D) [mm] 309 x 112 x 258 (without lens and feet)
Weight [kg] 3,1
Power Supply 100-240 V AC; 50 - 60 Hz
Power Consumption [W] 295 max.; 9 Stand-by Mode
Fan Noise [dB (A)] 29 Eco Mode
Safety and Ergonomics CE; TÜV GS; RoHS
Warranty Projector: 3 years pan-European Premium Service; Lamp: 6 Months, max. 1000 Hrs
Shipping Contents Projector; IR Remote Control (RD-427E); Mini D-SUB Signal Cable; Power Cord (4,5 m); Soft Case; Handle;
DVI-VGA Adapter; Users Manual on CD-ROM; Quick Setup Guide; Lens Cap
Optional Accessories Ceiling Mount Kit (NP03CM); Lamp (NP05LP); Mouse Receiver (NP01MR)
