Display 3 x 1.6 cm (0.63") p-Si LCD Panel with MLA
Lamp 210 W DC (172 W DC Eco Mode)
Lamp Life [hrs] 2500 (3500 Eco Mode)
Brightness 1 2700 ANSI Lumens (approx. 80% in Eco Mode)
Contrast Ratio 1 500:1
Lens F= 1.7–2.07, f= 18.9–22.7 mm
Diagonal: min. / max. [cm] 53 / 762
Projection Distance [m] 0.7 – 11.0
Projection Factor 1.5 – 1.8 : 1
Frequency Horizontal: 15–108 kHz (RGB: 24 kHz– 100 kHz); Vertical: 48 – 120 Hz
Native Resolution 1024 x 768 (XGA)
Supported Resolutions 1920 x 1080 (HDTV 1080i/60. HDTV 1080i/50); 1600 x 1200 (UXGA); 1280 x 1024 (SXGA); 1280 x 1024
(Mac 23"); 1280 x 720 (HDTV 720p); 1152 x 870 (Mac 21"); 832 x 624 (Mac 16"); 800 x 600 (SVGA);
720 x 576 (DVD progressive); 720 x 480 (DVD progressive); 720 x 480 (SDTV 480p); 640 x 480 (VGA/Mac
13"); 1024 x 768 (XGA) compressed
ComputerAnalog Input: 2 x Mini D-sub 15-pin, compatible to component (YPbPr);
Output: 1 x Mini D-sub 15 pin
HDMI™ Input: 1x HDMI™ (V.1.3 with Deep Color, Lip Sync) supporting HDCP
Video Input: 1 x RCA
S-Video Input: 1 x Mini DIN 4-pin
Audio Input: 2 x RCA Stereo for Video and S-Video; Input: 2 x 3.5 mm Stereo Mini Jack for Computer analog;
Output: 1 x 3.5 mm Stereo Mini Jack (variable)
PC Control Input: 1 x D-Sub 9 pin (RS-232) (male)
LAN 1 x RJ45, 10/100 base-T
USB 1 x Type A (USB 2.0 high speed)
Video Signals PAL / PAL60 / NTSC / SECAM / NTSC 4.43 / PAL-N / PAL-M
Audio Functions [W] 1 x 5 (mono)
Zoom / Focus Adjustment 1.2, manual / Manual
Benefits Windows Vista™ Network Projector; 3 W Power-saving Mode; Automatic and manual Keystone Correction
(V= ±30°, H= ±40°); Digital 3D Reform™; Direct Power-Off Function; High Altitude Mode; HQV™
Processing for best image quality; Off-Timer; Optional User Logo; OSD with 21 languages; Password
Security System; Picture in Picture / Picture and Picture; Program Timer; Quick Off Function; Remote
Desktop; Supports Windows Vista Network Functions; USB Viewer; Wall Colour Correction
Remote Control Aspect Ratio; Audio Control; Auto Adjust; Freeze-function; Help-function; Lamp Mode Control; Magnifyfunction; Optional Presentation and Mouse Control; Page (up, down); Picture Adjust; Picture Mute; Power
(On-OFF); Select (up, down, left, right); Source Select
Dimensions (W x H x D) [mm] 310 x 125 x 289 (without lens and feet)
Weight [kg] 3.7
Power Supply 100-240 V AC; 50 - 60 Hz
Power Consumption [W] 310 Normal Mode; 260 Eco Mode; 18 Stand-by Mode; 3 Power-saving Mode
Fan Noise [dB (A)] 29 Eco Mode
Safety and Ergonomics CE; TÜV GS; RoHS
Warranty Projector: 3 years pan-European Premium Service (Exchange Service); Lamp: 6 Months, max. 1000 Hrs
Shipping Contents Projector; IR Remote Control (RD-427E); Mini D-SUB Signal Cable; Power Cord (4.5 m); Soft Case; Handle;
Users Manual; Quick Setup Guide; Lens Cap
Optional Accessories Ceiling Mount Kit (NP07CM); Lamp (NP05LP); Mouse Receiver (Np01 MR)
