Projector type Single chip DLP projector
Resolution 2560 x 1600 (Native)
Brightness 6,700*² RGB ANSI lumens
Contrast ratio 2,000:1 – 8,000:1
Aspect ratio 16:10
Brightness uniformity 90%
Lens options N1: 0.80 – 1.25:1 @ WQXGA
N2: 1.20 – 1.60:1 @ WQXGA
N3: 0.63:1 @ 4K WQXGA
N4: 1.55:1 – 2.60:1 @ WQXGA
Lens shift (max) Vertical up to ±120.5% lens option dependent
Horizontal up to ±85% lens option dependent
Color correction P7
Light source(fully sealed optical architecture) SSI, NXL® + optional IR LED (standard IR wavelength is 740nm)
Illumination lifetime > 60,000 hours to 50% brightness (typical)
Optical block lifetime > 100,000 hours
Orientation Orientation free, no limitation
Inputs 2 x DisplayPort 1.4, 1 x HDMI 2.0
Input resolutions/Refresh 2560 x 1600. 4096 x 2176/3840 x 2400 – 1920 x 1200.
50Hz/60Hz/100Hz/120Hz
3D Active – up to WQXGA @120Hz
Latency 19 ms @60Hz/11.2 ms @120Hz
Bit depth Up to 12-bit*³
Embedded Warp & Blend Yes
Control IR, Ethernet, 2 x BNC (sync/trigger), 1 x Mini DIN, 3.5 mm RC and mini-USB
Software tools Unify™ Web, Unify™ Desktop
Power Requirements 100 – 240V, 50 – 60Hz
Power Consumption 880 W typical, 975 W maximum
Heat Dissipation 3,000 BTU/hour typical, 3,325 BTU/hour maximum
Ambient Noise 35 dB A typical/37 dB A maximum
Operating temperature 0 to 40°C/32 to 104°F (0 to 3000m)
Storage temperature -20 to 60°C/-4 to 140°F
Operating humidity 20 to 80% (non-condensing)
Storage humidity 10 to 90% (non-condensing)
Dimensions (L x W x H)(height excl. removeable feet) 488x505x241 mm/ 19.68×19.88×9.49 inch
Weight 22.6 kg/49.8 Ibs
Standard accessories Power cord, IR remote control & lens lock fixings
Certifications TBC
Warranty Limited 5 years parts & labor (extendable up to 10 years)
24/7 Yes
Errors & omissions exempt.
*¹ – 4K n-shift resolution is achieved using an n-shift actuator. *² – Product configuration dependent. *³ – Bit depth dependent on total
bandwidth, limitations apply at higher refresh rates.
