TECHNICAL SPECIFICATIONS

• 360 Operation: Yes
• Aspect Ratio: 16:9 (native), 16:10, 4:3, LBX and auto compatible
• Brightness: 7,500 ANSI lumens (8,000 center lumens)
• Compatible Aspect Ratio: 16:10 Native, 16:9 and 4:3 Compatible
• Contrast Ratio: 300,000:1 Dynamic, 2,000,000:1 Extreme Black enabled
• Control Unit: Complete on-screen menu adjustment in 12 languages
• Display Technology: Single Texas Instruments 0.67” DMD UHD
• Displayable Colors: 1.07 billion
• Image Size: 50” – 500” (dependent on installed lens)
• Light Source Type: Blue & red laser diodes
• Light Source Life: Up to 20,000 hours (30,000 hours Eco mode)
• Lens Shift: ±70° horizontal; ±30° vertical
• Maximum Resolution: 4K UHD (3840 x 2160, 60Hz)
• Native Resolution: 4K UHD (3840 x 2160)
• Noise Level: 32 dB (Eco)
• On-Screen Display: Complete on-screen menu adjustment in 12 languages
• Operating Temperature: 41–104°F (5–40°C), 85% max humidity
• Portrait Mode: Yes
• Power Consumption: 710W±10% typical (Normal mode), 410W±15% typical (Eco mode)
• Power Supply: AC input 100 – 240V, 50–60 Hz
• Projection Distance: 5.7’ – 370’
• Projection Lens: Interchangeable lenses (lens not included)
• Projection Method: Front, rear, ceiling mount, table top, 360˚ and portrait mode operation capable
• Projection Screen Size: 50" – 500" (dependent upon lens)
• Remote Control: Full function wired remote
• Throw Ratio: 0.85 – 10.18 (dependent on installed lens)
• Zoom Type: 1.25x-1.9x optical (dependent on installed lens), 0.8 – 2.0x digital

COMPATIBILITY SPECIFICATIONS

• 3D Compatibility: Supports all HDMI 1.4a mandatory 3D formats (Frame pack, side-by-side, top-bottom) and up converts frame rate from 60Hz to 120Hz or 24Hz to 144Hz (i.e 60 or 72 frames per eye).
• Computer Compatibility: VGA, SVGA, HDTV(720P), WXGA, WXGA+, SXGA, SXGA+, UXGA, HDTV(1080p), WUXGA, 4K UHD
• Horizontal Scan Rate: 15.375–91.146KHz
• Optional Wireless: Yes
• RoHS: Compliant
• Vertical Scan Rate: 24 – 85 Hz (120Hz for 3D feature)
• Video Compatiblity: PAL, SECAM, 576i/p, NTSC, 480i/p, HDTV 720p/1080i/1080p, 4K (3840×2160)

PHYSICAL SPECIFICATIONS

• Dimensions (W x H x D): 23.62” x 8.62” x 20.47” (w/o lens, w/o elevators)
• Security: Kensington® lock port, password (OSD)
• Weight: 72.75 lbs

OTHER

• Optional Accessories: Universal ceiling mount, DLP®Link™ 3D glasses, Wi-Fi dongle, Wireless HDMI system, remote
• Standard Accessories: AC power cord, VGA cable, remote control, carrying case, batteries for remote, multilingual CD-ROM user’s manual, quick start card, and warranty card
• UPC: 796435 44 377 1
• Warranty Info: 3 years or 20,000 hour light source warranty (whichever comes first), 3-year Optoma Express advance exchange warranty on the projector
