Specyfikacja

Display/image

Display technology

DLP

Resolution

WUXGA (1920x1200)

Brightness

5,500 lumens

ANSI brightness

5,500 lumens

Contrast ratio

300,000:1

Native aspect ratio

16:10

Aspect ratio - compatible

4:3,16:9,16:10

Keystone correction - horizontal

+/-30°

Keystone correction - vertical

+/-30°

Horizontal scan rate

15.375 ~ 91.146Khz

Vertical scan rate

24 ~ 85(120 for 3D)Hz

Uniformity

85%

Screen size

0.76m ~ 7.62m (30" ~ 300") (diagonal)

Lamp info

Light source type

Laser

LASER life

30,000 hours

Optical

Throw ratio

1.2:1 - 1.92:1

Projection distance (m)

1.24m - 8.27m

Zoom

1.6

Zoom type

Manual

Focal length (mm)

17.63 ~ 31.36

Lens shift

Vertical +20%, Horizontal +10%

Native offset

100%

Connectivity

Connections

Inputs 1 x VGA (YPbPr/RGB), 1 x Audio 3.5mm, 1 x Microphone, 1 x RS232, 1 x USB-A power 1.5A, 1 x USB-B service, 1 x Wired remote, 1 x RJ45, 1 x HDMI 1.4a 3D support + MHL, 1 x HDBaseT, 1 x HDMI 1.4a 3D support

Outputs 1 x VGA (YPbPr/RGB), 1 x Audio 3.5mm, 1 x 12V trigger

General

Noise level (typical)

28dB

PC compatibility

FHD, UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac

2D compatibility

NTSC M/J, 3.58MHz, 4.43MHz PAL B/D/G/H/I/M/N, 4,43MHz SECAM B/D/G/K/K1/L, 4.25/4.4MHz 480i/p, 576i/p, 720p(50/60Hz), 1080i(50/60Hz), 1080p(50/60Hz)

3D compatibility

Side-by-Side:1080i50 / 60, 720p50 / 60 Frame-pack: 1080p24, 720p50 / 60 Over-Under: 1080p24, 720p50 / 60

3D

Full 3D

Security

Security bar,Kensington Lock,Password protected interface

OSD / display languages

18 languages: Arabic,Danish,Dutch,English,Finnish,French,German,Italian,Japanese,Norwegian,Polish,Portuguese,Russian,Chinese (simplified),Spanish,Chinese (traditional),Turkish

24/7 operation

Yes

360° operation

Yes

Operating conditions

5°C ~ 40°C, Max. Humidity 90%, Max. Altitude 3000m

Remote control

Wired backlit PRO AV remote

Speaker count

2

Watts per speaker

10W

In the box

AC power cord

Remote control

2x AAA batteries

Basic user manual

Networking

LAN - control

Yes

Power

Power supply

100 ~ 240V, 50 ~ 60Hz

Power consumption (standby)

0.5W

Power consumption (min)

250W

Power consumption (max)

370W

Weight and dimensions

Net weight

10.7kg

Dimensions (W x D x H) mm

405 x 387 x 159
