Dane techniczne:

Screen size (diagonal) (inch)

64.5-inch

Screen size (diagonal) (mm)

1638 mm

Aspect Ratio

16:9

Panel Type

VA / Direct-LED

Effective display area (W x H) (mm)

1428 x 803 mm

Effective display area (W x H) (inch)

56.2" x 31.6"

Resolution

3840 x 2160

Brightness (typ.)

400 cd/m2

Contrast Ratio

5000 : 1

Response Time

8 ms (G to G)

Terminals | HDMI IN

HDMI TYPE-A Connector x 2

Terminals | PC IN/AUDIO IN (L/R)

Mini D-sub 15-pin x 1 (Female)/Stereo Mini Jack (M3) x 1

Terminals | USB

USB Connector (TYPE-A) x 1,

DC 5V/0.5A (USB 2.0 Supported)

Terminals | Serial

D-sub 9-pin x 1 (Input), RS-232C Compatible

Terminals | LAN

RJ45 x 1, 10 BASE-T / 100 BASE-TX

Built-in Speaker

20 W [10 W + 10 W]

Power Requirements

AC 110 - 127 V 50 Hz / 60 Hz

Power consumption

136w

Power Off Condition

Approx. 0.5 W

Standby Condition

Approx. 0.5 W

Dimensions (W x H x D) (mm)

1463 x 847 x 97 mm

Dimensions (W x H x D) (inch)

57.6" x 33.4" x 3.8"

Bezel width (mm)

T/R/L 15.9 mm B 19.9 mm

Bezel width (inch)

T/R/L 0.63" B 0.78"

Weight (kg)

Approx.33 kg

Weight (lbs.)

Approx. 72.8 lbs

Wall-hanging pitch (mm)

400 x 200 mm VESA compliant

Wall-hanging pitch (inch)

VESA Compliant 15.7" x 7.9" (400 x 200 mm) (Installed by: M6 screws / Screw hole depth 0.7" (17 mm))

Operating environment

Temperature : 32°F to 104°F (0℃ to 40℃)*1 : 32°F to 95°F (0℃ to 35℃)*2

Humidity : 20% to 80% (No condensation)

Operating Time

16 h/day

Viewing angle [(T/B)/(L/R)]

178° / 178° (CR≧20)

Terminals | AUDIO OUT

Pin Jack x 1
