Dane techniczne:

Screen size (diagonal) (inch)

74.7-inch

Screen size (diagonal) (mm)

1898 mm

Aspect Ratio

16:9

Panel Type

IPS Panel / Direct-LED

Effective display area (W x H) (mm)

1654 x 932 mm

Effective display area (W x H) (inch)

36.1" x 36.6"

Resolution

3840 x 2160

Brightness (typ.)

400 cd/m2

Contrast Ratio

1400 : 1

Response Time

8 ms (G to G)

Terminals | HDMI IN

HDMI Type A Connector x 2

Terminals | PC IN/AUDIO IN (L/R)

Mini D-Sub 15-pin (DDC2B) x 1

Terminals | USB

USB Type A Connector x 1, DC 5 V/0.5 A (USB 2.0 is supported)

Terminals | Serial

D-sub 9pin x 1, RS-232C Compatible

Terminals | LAN

RJ45 x 1

RJ45 10BASE-T/100BASE-TX

Built-in Speaker

20 W [10 W + 10 W]

Power Requirements

AC 110 - 127 V 50 Hz / 60 Hz

Power consumption

274 W

Power Off Condition

Approx. 0.5 W

Standby Condition

Approx. 0.5 W

Dimensions (W x H x D) (mm)

1684 x 969 x 94 mm

Dimensions (W x H x D) (inch)

66.3" x 38.1" x 3.7"

Bezel width (mm)

T/R/L 14.9 mm) B 18.4 mm

Bezel width (inch)

T/R/L 0.59"  B 0.73"

Weight (kg)

Approx. 34 kg

Weight (lbs.)

Approx. 75.0 lbs

Wall-hanging pitch (mm)

VESA Compliant 400 x 400 mm (Installed by: M6 screws / Screw hole depth  (18 mm)

Wall-hanging pitch (inch)

VESA Compliant 15.7" x 15.7" (Installed by: M6 screws / Screw hole depth 0.7"

Operating environment

Temperature : 32°F to 104°F (0℃ to 40℃)*1 : 32°F to 95°F (0℃ to 35℃)*2

Humidity : 20% to 80% (No condensation)

Operating Time

16 h/day

Viewing angle [(T/B)/(L/R)]

178° / 178° (CR>10)

Terminals | AUDIO OUT

RCA Terminal (L / R) x 1

Variable (- ∞ - 0 dB) (1 kHz 0 dB Input,10 kΩ Load)
