Dane techniczne:

Screen size (diagonal) (inch)

86-inch

Screen size (diagonal) (mm)

2177.4 mm

Aspect Ratio

16:9

Panel Type

IPS Panel / Edge LED

Effective display area (W x H) (mm)

1897 x 1068 mm

Effective display area (W x H) (inch)

74.70 x 42.00 inch

Resolution

3840 x 2160

Brightness (typ.)

400 cd/m2

Contrast Ratio

1200 : 1

Response Time

8 ms (G to G)

Terminals | HDMI IN

HDMI TYPE-A Connector x 2

Terminals | PC IN/AUDIO IN (L/R)

Mini D-sub 15-pin x 1 (Female)/Stereo Mini Jack (M3) x 1

Terminals | USB

USB Type A Connector x 1, DC 5 V/0.5 A (USB 2.0 is supported)

Terminals | Serial

D-sub 9-pin x 1 (Input), RS-232C Compatible

Terminals | LAN

RJ45 x 1, 10BASE-T/100BASE-TX

Built-in Speaker

20 W [10 W + 10 W]

Power Requirements

AC 110 - 127 V 50 Hz / 60 Hz

Power consumption

340 W

Power Off Condition

Approx. 0.5 W

Standby Condition

Approx. 0.5 W

Dimensions (W x H x D) (mm)

1929 x 1103 x 80 mm

Dimensions (W x H x D) (inch)

76.0" x 43.5" x 3.2"

Bezel width (mm)

(T/B/L/R 15.3 mm)

Bezel width (inch)

T/B/L/R 0.61"

Weight (kg)

Approx.50 kg

Weight (lbs.)

Approx. 110.3 lbs

Wall-hanging pitch (mm)

VESA Compliant 600 x 400 m)

Wall-hanging pitch (inch)

VESA Compliant 23.6" x 15.7"

Operating environment

Temperature : 32°F to 104°F (0℃ to 40℃)*1 : 32°F to 95°F (0℃ to 35℃)*2

Humidity : 20% to 80% (No condensation)

Operating Time

16 h/day

Viewing angle [(T/B)/(L/R)]

178° / 178° (CR>10)

Terminals | AUDIO OUT

RCA Terminal (L / R) x 1
