Screen size (diagonal) (inch) 74.5 inch
Screen size (diagonal) (mm) 1892.7 mm
Aspect Ratio 16:9
Panel Type IPS / Edge LED
Effective display area (W x H) (mm) 1649.6 mm / 927.9 mm
Effective display area (W x H) (inch) 64.94" / 36.53"
Resolution 3840 x 2160
Brightness (typ.) 500 cd/m2
Contrast Ratio 1200:1
Dynamic Contrast ratio 50000:1
Response Time 8.0 ms (G to G)
Viewing angle [(T/B)/(L/R)] 178°/ 178° (CR≧10)
Panel Surface Treatment Anti glare type (Haze 28%)
Terminals | HDMI In HDMI Type A Connector x 2(Compatible with HDCP 2.2)AUDIO: Linear PCM (Sampling frequency：48 kHz/44.1 kHz/32 kHz)
Terminals | DVI-D IN/AUDIO IN (L/R) DVI-D 24-pin x 1 (Compatible with HDCP 1.1) Compliance with DVI Revision 1.0
Terminals | PC IN/AUDIO IN (L/R) Mini D-Sub 15-pin (DDC2B) x 1 Y/GPB/CB/BPR/CR/RHD/VD: with sync 1.0 V [p-p] (75 Ω): without sync 0.7 V [p-p] (75 Ω): without sync 0.7 V [p-p] (75 Ω): without sync 0.7 V [p-p] (75 Ω): HD/VD TTL (high impedance)
Terminals | DisplayPort IN Display Port x 1(Compatible with HDCP 2.2)AUDIO: Linear PCM (Sampling frequency：48 kHz/44.1 kHz/32 kHz)
Terminals | DisplayPort OUT Display Port x 1 (Compatible with HDCP 1.4)
Terminals | USB USB Connector (Type A) x 2, DC 5 V/2A, DC 5 V/1A (USB 3.0 is supported)
Terminals | Serial D-sub 9-pin x 1, RS-232C Compatible
Terminal | LAN RJ45 x 1 compatible with PJLinkTMRJ45 10BASE10-T/100BASE-TX
Terminal | DIGITAL LINK RJ45 x 1 100BASE-TX, compatible with Long reach mode (Compatible with HDCP 2.2)
Terminals | Slot Intel® SDM specificationCorresponding size SDM-S / SDM-L, Supply power 3.3 V / 1.1 A, 12 V / 5.5 A
Terminals | IR IN / OUT Stereo Mini Jack (M3) x 1 / x 1
Terminals | Audio Out Stereo Mini Jack (M3) x 1　 0.5 V [rms]Variable (- ∞ - 0 dB) (1 kHz 0 dB Input,10 kΩ Load)
Built-in Speaker 20 W [10 W + 10 W]
Power Requirements AC 110 - 240 V 50 Hz / 60 Hz
Power Consumption 385 W
Power Off Condition approx. 0.3 W
Stand-by Condition approx. 0.5 W
Dimensions (W x H x D) (mm) 1681 x 959 x 73 mm *Including handles
Dimensions (W x H x D) (inch) 66.15" x 37.75" x 2.87" *Including handles
Bezel width (mm) T/B/L/R: 14.8 mm
Bezel width (inch) T/B/L/R: 0.58"
Weight (kg) approx. 56.0 kg
Weight (lbs.) 123.5 lbs
Gross Weight (kg) 71 kg
Gross Weight (lbs.) 156.6 lbs
Wall-hanging pitch (mm) VESA Compliant W 600 x H 400 mm (Installed by: M6 screws / Screw hole depth 10 mm)
Orientation Landscape/Portrait
Tilting angle Landscape : 0 - 45 degrees forward / backwardPortrait : 0 - 20 degrees forward / backward
Operating Time 24h / day
Operating environment | Temperature 0 °C to 40 °C
Operating Environment | Humidity 20% to 80% (No condensation)
