Strona głównaPROJEKTORY MULTIMEDIALNEPANASONICProjektor Panasonic PT-RQ22 (PT-RQ22K)
Panasonic

Projektor Panasonic PT-RQ22 (PT-RQ22K)

OTRZYMAJ RABAT DODATKOWY NAWET 40%* W każdej chwili możesz się wypisać
Zapisując się do Newslettera, otrzymasz RABAT do 40%* Możesz wypisać się w każdej chwili
Pola wymagane
Cena na telefon

Zapytanie o produkt Projektor Panasonic PT-RQ22 (PT-RQ22K)

TokenZmień
Pola wymagane
Produkt niedostępny

Negocjuj cenę

TokenZmień
Pola wymagane
downloadPobierz kartę produktu
Model PT-RQ22K
DLP™ chip 22.9 mm (0.9 in) diagonal (16:10 aspect ratio)
DLP™ chip x 3, DLP™ projection system
Panel size
Display method
Pixels 49,152,000 (12,288,000 x 4) pixels with Quad Pixel Drive set to ON, 4,096,000 (2560 x 1600) x 3, total of 12,288,000 pixels with Quad Pixel Drive set to OFF
Refresh rate 240 Hz*1
Lens Optional (no lens included with this model)
Light source Laser diodes (Laser class: Class 1) (Class 3R for US models), Light source life: 20,000 hours (NORMAL mode, brightness decreases to approx. 50 %)
Screen size (diagonal) 1.78–25.4 m (70–1,000 in) with 16:10 aspect ratio
1.78–15.24 m (70–600 in) with the ET-D75LE8 / ET-D3LET80, 16:10 aspect ratio
3.05–15.24 m (120–600 in) with the ET-D75LE95, 16:10 aspect ratio
Center-to-corner uniformity*3 90 %
Brightness 21,000 lm (Center)*2
 / 20,000 lm*3
 (HIGH Mode)*4
Contrast*3 20,000:1 (Full On/Full Off, Dynamic Contrast Mode: 3)
Resolution 4K+ (5120 x 3200) (Quad Pixel Drive: ON)
Optical
axis shift*5
Vertical (from center of screen) ±59 % (±56 % with ET-D75LE6 / ET-D3LEW60, +69 % – +84 % with ET-D75LE95) (powered)
Horizontal (from center of screen) ±29 % (±19 % with ET-D75LE6 / ET-D3LEW60, ±21 % with ET-D75LE95) (powered)
Keystone correction range Vertical: ±40° (± 22° with ET-D75LE50 / ET-D3LEW50, ±28° with ET-D75LE6 / ET-D3LEW60, +5° with ET-D75LE95),
Horizontal: ±15° (0° with ET-D75LE95)
Keystone correction range
with optional Upgrade Kit ET-UK20
Vertical: ±45° (± 40° with ET-D75LE10 / ET-D3LEW10, ET-D75LE20 / ET-D3LES20, ±22° with ET-D75LE50 / ET-D3LEW50,
±28° with ET-D75LE6 / ET-D3LEW60, +5° with ET-D75LE95)
Horizontal: ±40° (±15° with ET-D75LE50 / ET-D3LEW50, ET-D75LE6 / ET-D3LEW60, ET-D75LE10 / ET-D3LEW10, 0° with ET-D75LE95),
Up to a total of ±30° during simultaneous horizontal and vertical correction
Installation Horizontal/vertical, free 360-degree installation
Terminals SDI 1 IN BNC x 1: 3G/HD/SD-SDI input, Dual-link HD-SDI (Link-A), Dual-link 3G-SDI (Link 1), Quad-link HD-SDI (Link 1), Quad-link 3G-SDI (Link 1)
SDI 2 IN BNC x 1: 3G/HD/SD-SDI input, Dual-link HD-SDI (Link-B), Dual-link 3G-SDI (Link 2), Quad-link HD-SDI (Link 2), Quad-link 3G-SDI (Link 2)
SDI 3 IN BNC x 1: 3G/HD/SD-SDI input, Dual-link HD-SDI (Link-C), Dual-link 3G-SDI (Link 3), Quad-link HD-SDI (Link 3), Quad-link 3G-SDI (Link 3)
SDI 4 IN BNC x 1: 3G/HD/SD-SDI input, Dual-link HD-SDI (Link-D), Dual-link 3G-SDI (Link 4), Quad-link HD-SDI (Link 4), Quad-link 3G-SDI (Link 4)
MULTI PROJECTOR SYNC IN BNC x 1
MULTI PROJECTOR SYNC OUT BNC x 1
SERIAL IN D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
SERIAL OUT D-sub 9-pin (male) x 1 for link control
REMOTE 1 IN M3 x 1 for wired remote control, link control
REMOTE 1 OUT M3 x 1 for wired remote control, link control
REMOTE 2 IN D-sub 9-pin (female) x 1 for external control (parallel)
LAN/DIGITAL LINK RJ-45 x 1 for network, DIGITAL LINK connection (HDBaseT™ compliant), 100Base-TX, compatible with Art-Net, PJLink™ (Class 2), Deep Color, HDCP2.2
DC OUT USB Type A x 2 (for power supply DC 5V total of 2 A)
Expansion Slot SLOT 1 / SLOT 2 (total two terminals, vacant) for interface boards, SLOT NX compatible
Cabinet materials Molded plastic
Dimensions (W x H x D) 598 x 270 x 725 mm (23 1/32˝ x 10 5/8˝ x 28 17/32˝ ) (not including protruding parts)
Weight*6 Approx. 55 kg (122 lbs)
Operation noise*3 TBD
Power supply AC 200–240 V, 50/60 Hz; AC 100–200 V, 50/60 Hz (brightness is restricted with lower voltage)
Power consumption TBD
Operating environment Operating temperature: 0–45 °C (32–113 °F)*7
, operating humidity: 10–80 % (no condensation)
Applicable software Logo Transfer Software, Multi Monitoring & Control Software, Geometry Manager Pro (ET-UK20 Upgrade Kit)
Fixed-Focus Lens
ET-D75LE50 / ET-D3LEW50,
ET-D75LE95
Fisheye Lens
ET-D3LEF70
Interface Board for
DVI Input (Input x 2)
ET-MDNDV10
Interface Board for HDMI
(HDCP2.2) Input (Input x 2)
ET-MDNHM10
Interface Board for
3G-SDI Input (Input x 4)
TY-TBN03G
Interface Board for 12G-SDI Input
(Input x 2, Output x 2)
ET-MDN12G10
Geometry Manager Pro
Software Upgrade Kit
ET-UK20
*1 Refresh-rate varies depending on vertical scanning frequency. *2 Luminance measured at center of screen (in HIGH Mode). *3 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2012 international standards. Value is average of all products
when shipped. *4 Operation in HIGH Mode may reduce maintenance timing in comparison to use in NORMAL Mode. *5 Optical axis shift is not supported on the ET-D75LE50/ET-D3LEW50. *6 Average value. May differ depending on the actual unit. *7 Light source brightness may

decrease depending on operating temperature. When projector is operating at high temperature or at high altitude, brightness will decrease correspondingly
