Power Supply AC 100-120 V, 200-240 V, 50/60 Hz

(Note: Brightness may decrease depending on power conditions)

Power Consumption TBD

DLP™ chip Panel Size 24.4 mm (0.96 in)

diagonal (16:10 aspect ratio)

Display Method DLP™ chip x 3, DLP™ projection system

Pixels 6,912,000 (1,920 x 1200 x 3) pixels

Refresh Rate 120 Hz*1

Lens Optional (no lens included with this model), powered zoom, powered focus

Light Source Dual-laser bank system, 50% of brightness at 20,000 hours

Screen Size (diagonal) 1.78-25.4 m (70-1,000 in),

1.78-15.24 m (70-600 in)

with the ET-D75LE8,

3.05-15.24 m (120-600 in)

with the ET-D75LE90,

16:10 aspect ratio

Brightness*2 12,000 lm (AC 200-240V)

Corner-to-Corner Uniformity*2 90%

Contrast*2 20,000:1 (full on/off, with dynamic contrast on)

Resolution 1,920 x 1,200 pixels*3 (with RGB signal input)

Scanning Frequency SDI 3G-SDI SMPTE ST 424 compliant,

[RGB 4:4:4 12-bit /10-bit] 1080/60i, 1080/50i, 1080/25p, 1080/24p, 1080/24sF, 1080/30p

[YPBPR 4:2:2 10-bit] 1080/60p, 1080/50p

HD-SDI SMPTE ST 292 compliant,

[YPBPR 4:2:2 10-bit] 720/60p, 720/50p, 1035/60i, 1080/60i, 1080/50i,

1080/25p, 1080/24p, 1080/24sF, 1080/30p

SD-SDI SMPTE ST 259 compliant, [YCBCR 4:2:2 10-bit] 480i, 576i

Dual-link HD-SDI SMPTE ST 372 compliant,

[RGB 4:4:4 12-bit /10-bit] 1080/60i, 1080/50i, 1080/25p, 1080/24p, 1080/24sF, 1080/30p,

[X´Y´Z´ 4:4:4 12-bit] 2048 x 1080/24p, 2048 x 1080/24sF

Dual-link 3G-SDI SMPTE ST 425 compliant,

[YPBPR 4:4:4 12-bit / 10-bit] 1080/60p, 1080/50p, 2048 x 1080/60p,

2048 x 1080/50p, 2048 x 1080/48p,

[RGB 4:4:4 12-bit / 10-bit] 1080/60p, 1080/50p, 2048 x 1080/60p, 2048 x 1080/50p, 2048 x 1080/48p

HDMI/DVI-D Compatible with HDCP, 480i(525i),*4 576i(625i),*4

480p(525p), 576p(625p), 720(750)/60p,

720(750)/50p, 1080(1125)/60i, 1080(1125)/50i,

1080(1125)/25p, 1080(1125)/24p,

1080(1125)/24sF, 1080(1125)/30p,

1080(1125)/60p, 1080(1125)/50p,

VGA (640 x 480)-WUXGA*5 (1,920 x 1,200)

(compatible with non-interlaced signals only),

dot clock: 25-162 MHz

RGB fH: 15-100 kHz, fV: 24-120 Hz, dot clock: 20-162 MHz

YPBPR (YCBCR) fH: 15.75 kHz, fV: 60 Hz [480i (525i)]

fH: 31.50 kHz, fV: 60 Hz [480p (525p)]

fH: 15.63 kHz, fV: 50 Hz [576i (625i)]

fH: 31.25 kHz, fV: 50 Hz [576p (625p)]

fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]

fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]

fH: 33.75 kHz, fV: 60 Hz [1035 (1125)/60i]

fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i]

fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]

fH: 28.13 kHz, fV: 25 Hz [1080 (1125)/25p]

fH: 27.00 kHz, fV: 24 Hz [1080 (1125)/24p]

fH: 27.00 kHz, fV: 48 Hz [1080 (1125)/24sF]

fH: 33.75 kHz, fV: 30 Hz [1080 (1125)/30p]

fH: 67.50 kHz, fV: 60 Hz [1080 (1125)/60p]

fH: 56.25 kHz, fV: 50 Hz [1080 (1125)/50p]

Video/YC fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60],

fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]

Optical

Axis Shift*7 Vertical ±55 %

(±44 % with the ET-D75LE6,

+73 - +78 % with the

ET-D75LE90) (powered)

Horizontal ±20 %

(±15 % with the ET-D75LE6,

±6 % with the

ET-D75LE90) (powered)

Keystone Correction Range Vertical: ±40°*7, horizontal: ±15°

Keystone correction range with the

optional upgrade kit ET-UK20 Vertical: ±45°, horizontal: ±40°*8

Installation Horizontal/vertical, free 360-degree installation

Terminals SDI 1 IN BNC x 1: 3G/HD/SD-SDI input, Dual-link input (LINK-A)

SDI 2 IN BNC x 1: 3G/HD/SD-SDI input, Dual-link input (LINK-B)

HDMI IN HDMI 19-pin x 1 (Deep Colour, compatible with HDCP)

DVI-D IN DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP, compatible with single link only)

RGB 1 IN BNC x 5 (RGB/YPBPR/YCBCR/VIDEO/YC x 1)

RGB 2 IN D-Sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR x 1)

3D SYNC IN/OUT BNC x 1 (3D timing signal)

3D SYNC OUT BNC x 1 (3D timing signal)

SERIAL IN D-sub 9-pin (female) x 1 for external control (RS-232C compliant)

SERIAL OUT D-sub 9-pin (male) x 1 for link control

REMOTE 1 IN M3 x 1 for wired remote control

REMOTE 1 OUT M3 x 1 for link control (for wired remote control)

REMOTE 2 IN D-sub 9-pin (female) x 1 for external control (parallel)

LAN/DIGITAL LINK RJ-45 x 1 (for network, DIGITAL LINK connection, 100Base-TX, compatible with Art-Net, PJLink™ (class 1), Deep Colour, HDCP)

Cabinet Materials Moulded plastic

Dimensions (W x H x D) 578 x 270 x 725 mm (22-3/4 x 10-5/8 x 28-17/32 in)

Weight*9 Approx. 45 kg (99.2 lbs)

(optional lens not included)

Operation Noise*2 TBD

Operating Environment Operating temperature: 0-45°C (32-113°F)*10,

operating humidity: 10-80 % (no condensation)

Applicable Software Logo Transfer Software,

Multi Monitoring & Control Software, Early Warning Software,

Geometry Manager Pro (ET-UK20 Upgrade Kit and ET-CUK10*11 Auto Screen Adjustment Kit)

Supplied Accessories Power cord with secure lock, wireless/wired remote control unit, batteries (R6/AA type x 2), software CD-ROM (Logo Transfer Software, Multi Monitoring & Control Software)

NOTE * 1 Refresh rate varies depending on scanning frequency.

*2 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.

*3 Input signals that exceed the native resolution will be converted to the native resolution.

*4 Only compatible with dot clock frequency of 27 MHz (pixel repetition signal).

*5 WUXGA resolution is supported only when the signals are compliant with VESA CVT-RB (Coordinated Video Timing-Reduced Blanking).

*6 Optical axis shift is not supported on the ET-D75LE50.

*7 Vertical ±22 ° with ET-D75LE50. Vertical 28 ° with ET-D75LE6.

*8 Up to a total of ±55 ° during simultaneous horizontal and vertical correction. Vertical ±22 ° and horizontal ±15 ° with ET-D75LE50.

Vertical ±28 ° and horizontal ±15 ° with ET-D75LE6. Vertical ±40 ° and horizontal ±40 ° with ET-D75LE10/D75LE20.

*9 Average value. May differ depending on the actual unit.

*10 Operating temperature range is 0-40 °C (32-104 °F) in High Altitude mode at altitudes of 1,400–2,700 m (4,593–8,858 ft) above sea level.

*11 Available worldwide except in the United States.
