Projector Technology     3 x DLP
Horizontal resolution     1920 Pixel
Vertical resolution     1200 Pixel
Chip size     0,96 ''
Aspect ratio     16:10
Brightness (ANSI)     20000 lm
Brightness (Center)     21000 lm
Contrast     20000 : 1
Lamp system     Laser Phosphor
Lens shift vertical     110 %
Lens shift horizontal     40 %
Lens type     ET-D75
3D-ability     yes
Supported 3D standards     top bottom
active
shutter
passive
side by side
2 channels
frame sequential
Additional features     edge blending
High Frame Rate
Digital Link
lens memory
warping
360° x 360° Installation
24/7 Operation
Noise level     46 dB(A)
Power consumption     1.510,00 W
Electrical connection     Grounding type plug to IEC C19
Inputs and Outputs
Number of DVI inputs     1
Number of HDMI inputs     1
Number of SDI inputs     2
Number of analog inputs     2
Supported DVI standards     single link DVI up to 165 MHZ
Supported HDMI standards     HDMI 1.4
Supported SDI standards     SMPTE 259M / SD-SDI / 480i, 576i
SMPTE 425M / 3G-LvA-SDI / 1080p(50/60)
SMPTE 425M / 3G-LvB(DL)-SDI / 1080p(50/60)
SMPTE 292M / HD-SDI / 720p, 1080i
SMPTE 372M / dual HD-SDI / 1080p
SMPTE 425M / 3G-LvB(DS)-SDI / 2*1080i(50/60)
Supported analogue standards     data signal
video signal
YUV component
s-video
Component (5BNC)
Control
Remote interface     RJ45 / LAN
remote control
3,5mm phone jack
d - sub serial 232
Operating interface     infrared remote control
