Panel
Diagonal Size
55"

Type
VA
Resolution
3840x2160(16:9)

Pixel Pitch(mm)
0.315 x 0.315
Active Display Area(mm)
1209.6(H) x 680.4(V)
Brightness(Typ.)
500 (without Glass) nit

Contrast Ratio
4000:1
Viewing Angle(H/V)
178/178

Color Gamut
92% (DCI-P3, CIE 1976)
Operation Hour
24/7

Haze
25% (without Glass)
Sound
Speaker Type
10W 2ch
Connectivity
Input
Video
DP 1.2 (1), HDMI 2.0 (3)

HDCP
HDCP2.2
USB
USB 2.0 x 2
Output
Audio
Stereo mini Jack
Usb
Touch out 2 (PC/screen)
External Control
RS232C(in/out), RJ45

BT/WiFi
Yes / Yes
Power
Power Supply
AC 100 - 240 V, 50/60 Hz
Power Consumption
Max[W/h]
143

Typical[W/h]
108

Sleep mode
less than 0.5W
Mechanical Specification
Dimension (mm)
Set
1253.8 x 734.6 x 56.7 mm
Package
1421 x 884 x 165 mm
Weight (kg)
Set
26.9 kg
Package
32.5 kg
VESA Mount (mm)
200 X 200
Bezel Width (mm)
26.0/26.0/21.0/21.0 (U/D/L/R)
Operation
Operating Temperature
0 ℃ ~ 40 ℃

Humidity
10 % ~ 80 %
Feature
Key Features
UHD Signage with Built-in MagicInfo S10, SSSP 10.0

Orientation
Landscape / Portrait

Remote Control
N/A
Special Features
H/W : Symmetric Design (same with QxR), Center IR, Temperature Sensor, Auto Level, Wi-Fi(2.4/5.0GHz dual) & BT S/W : Workspace (Microsoft365/VMWare/RDP), Custom Home, Auto Source Switching & Recovery, Dicom Simulation Mode, Director Mode, Upgradable Web-Engine, Tizen Enterprise Platform, Video Conference Solution, [end of June~] Smart Calibration
Internal Player
Processor
Cortex A72 1.7GHz Quad-Core CPU

On-Chip Cache Memory
N/A

Clock Speed
N/A

Main Memory Interface
N/A
Graphics
N/A

Storage (FDM)
16 GB

Multimedia
N/A

IO Ports
N/A
Operating System
Tizen 6.5
Certification
Safety
60950-1 / 62368-1

EMC
Class B

IP Rating
IP5x

Security
802.1x(WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP
Accessory
Included
Quick Setup Guide, Warranty Card, Power Cord, RS232C(IN) Gender, Remote Controller & Batteries
Optional
Stand
STN-L4355G

Mount
WMN4070SG (Land Only) WMN750ME

Specialty
CML400XR
Media Player
Media Player
Media Player
N/A
