Panel
Diagonal Size
75"

Type
Direct LED BLU (mini LED)
Resolution
7680*4320 (8K UHD)

Pixel Pitch(mm)
214.86 * 214.86 um
Active Display Area(mm)
1650.1248(H) x 928.1952 (V)
Brightness(Typ.)
500 (HDR 2,000nit) nit

Contrast Ratio
1200:1
Viewing Angle(H/V)
178/178

Response Time(G-to-G)
6.5ms
Display Colors
1.07B
Color Gamut
93% (DCI-P3)
Operation Hour
16/7

Haze
2%
Display
Dynamic C/R
MEGA
H-Scanning Frequency
270 HZ
V-Scanning Frequency
120 HZ
Maximum Pixel Frequency
2.376GHz
Sound
Speaker Type
Built in Speaker(70W 4.2.2ch)
Connectivity
Input
Video
HDMI 2.1 (HDMI4), HDMI 2.0 (HDMI1,2,3)

HDCP
HDCP2.2
Audio
-
USB
USB 2.0 x 3
Output
Audio
Digital Audio Out (Optcal)
External Control
RS232C(in) thru stereo jack, RJ45
Power
Type
Internal (OC Box)
Power Supply
AC100-240V 50/60Hz
Power Consumption
Max[W/h]
407.0

Typical[W/h]
320.0

Rating[W/h]
370.0
BTU(Max)
1387.87
Sleep mode
0.5
Mechanical Specification
Dimension (mm)
Set
1668.3 x 955.6 x 17.2 (w/o stand)
Package
1872 x 1144 x 196
Weight (kg)
Set
32.1 (w/o stand)
Package
57.5
VESA Mount (mm)
400 x 400
Bezel Width (mm)
4 bezel-less
Operation
Operating Temperature
0 ℃ ~ 40 ℃

Humidity
10.0 % ~ 80.0 %
Feature
Key Features
8K Signage Display Built-in MagicInfo S9, SSSP, HDR10+

Orientation
Landscape / Portrait

Remote Control
N/A
Special Features
H/W : Temperature Sensor, Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(70W 4.2.2ch),Wi-Fi/BT S/W : Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting)
Internal Player
Processor
CA76 Quad (1.66GHz)

On-Chip Cache Memory
L1 Instruction Cache : 64KB L1 Data Cache : 64KB L2 Cache : 256KB L3 Cache : 2MB

Clock Speed
1.66GHz

Main Memory Interface
5GB LPDDR4 1866MHz 128bit
Graphics
Graphic resolution : 3840x2160 Output resolution : 7680x4320 (Scale up from graphic processing result.)

Storage (FDM)
16GB (5.8GB Occupied by O/S, 10.2GB Available)

Multimedia
*Video Decoder : H.264, HEVC, Motion JPEG, MVC, MPEG-1/2/4, VC1, WMV1, WMV2, H.263, VP6, AV1, VP8, VP9, RV8/9/10 *Audio Decoder : DD, DD+, LPCM, ADPCM, AAC, HE-AAC, WMA, MPEG, AC-4, G.711, OPUS, Vorbis, RealAudio6

IO Ports
USB 2.0
Operating System
Tizen 6.0 (VDLinux)
Certification
Safety
60065, 62368-1

EMC
Class B
Accessory
Included
Quick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries
Optional
Stand
In Box

Mount
N/A

Specialty
N/A
Media Player
Media Player
Media Player
N/A
