Dane techniczne

• Przekątna: 46"/​116.8cm
• Rozdzielczość: 1920x1080, 16:9
• Jasność: 4000cd/​m²
• Kontrast: 5.000:1 (statyczny), 10.000:1 (dynamiczny)
• Czas reakcji: 6ms
• Kąt widzenia: 178°/​178°
• Panel: VA
• Częstotliwość odświeżania: 60Hz
• Złącza: 2x HDMI 2.0, 1x DisplayPort 1.2
• Dodatkowe złącza: 1x LAN, 1x port szeregowy, 1x USB 2.0
• VESA: brak
• Pobór mocy: 350W (maksimum), 210W (praca), 0.5W (czuwanie)
• Wymiary (SxWxG): 616.6x1062x54.5mm
• Waga: 18.20kg
• Cechy szczególne: podświetlenie LED, wyświetlacz dual (przód i tył), HDCP 2.2, głośniki (2x 10W), WLAN, Tizen OS, zintegrowany odtwarzacz multimedialny

Panel

Diagonal Size46"

TypeE-LED BLU

Resolution1920*1080 (Full HD)

Pixel Pitch(mm)0.530 x 0.530

Active Display Area(mm)1018.08(H) x 572.67(V)

Brightness(Typ.)3000 / 1000 nit

Contrast Ratio5000:1

Viewing Angle(H/V)178/178

Response Time(G-to-G)6ms

Display Colors8 bit - 16.7M

Color Gamut72%

Operation Hour24/7

Haze0%

Display

Dynamic C/R100,000:1

H-Scanning Frequency15 ~ 135kHz (HDMI)

V-Scanning Frequency24 ~ 75Hz (HDMI)

Maximum Pixel Frequency594MHz (HDMI)

Sound

Speaker TypeN/A

Connectivity

Input

RGBN/A

VideoHDMI2.0 (2)

HDCPHDCP 2.2

AudioN/A

USBUSB 2.0 (2)

Output

RGBN/A

VideoN/A

AudioN/A

Power OutN/A

External ControlRS232C (In), RJ45 (In)

External SensorDetachable Type (IR, Ambient)

TunerN/A

Power

TypeInternal

Power SupplyAC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption

Max[W/h]380

Typical[W/h]W/W(EU) : 214 US/KOR/Etc : 380 ※ Etc: CHINA, TAIWAN, BRA, CIS

BTU(Max)1297

Sleep modeless than 1W

Off modeless than 0.5W

Mechanical Specification

Dimension (mm)

Set619.1 x 1107.5 x 69.5 mm

Package796 x 1255 x 327 mm

Weight (kg)

Set32kg

Package39.5kg

VESA Mount (mm)N/A

Protection GlassN/A

Stand TypeN/A

Media Player Option TypeN/A

Bezel Width (mm)22.8 (even)

Operation

Operating Temperature0℃~ 30℃ (Direct Sunlight) 0℃~ 40℃ (w/o Direct Sunlight)

Humidity10  %  ~   80   %

Feature

Key FeaturesDual Display Slim design Semi-OutdoorBuilt-in MagicInfo Player S6, SSSP 6.0

Special FeaturesIP 5X rated, Polarized Sun Glasses Viewable in any direction, Portrait Installation Support, Auto Brightness Control with Ambient Brightness Sensor, Temperature Sensor, RJ45 MDC, Auto Source Switching & Recovery, Clock Battery(80hrs Clock Keeping), WiFi Module Embedded (2ea, one per each display)

Internal Player

ProcessorCortex A72 1.7GHz Quad-Core CPU

On-Chip Cache MemoryL1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB

Clock Speed1.7GHz

Main Memory Interface2.5GB LPDDR4 1.5GHz 64bit

GraphicsGraphic resolution : 1920x1080 Output resolution : up to 3840x2160 (Scale up from graphic processing result.) - Supports OpenGL ES

Storage (FDM)8GB (3.88GB Occupied by O/S, 4.12GB Available)

MultimediaVideo Decoder - MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC - VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 Audio Decoder - AC3 (DD), MPEG

IO PortsUSB 2.0

Operating SystemTizen 4.0 (VDLinux)

Certification

Safety60950-1

EMCClass A

Accessory

IncludedQuick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote Controller, Batteries
