Panel
Diagonal Size
85"

Type
Edge LED BLU
Resolution
3840*2160 (4K UHD)

Pixel Pitch(mm)
0.4875 x 0.4875
Active Display Area(mm)
1872.0(H) x 1053.01(V)
Brightness(Typ.)
350 nit

Contrast Ratio
4000:1
Viewing Angle(H/V)
178/178

Response Time(G-to-G)
8ms(Typ.)
Display Colors
16.7M(True Display) 1.07B(Ditherd 10bit)
Color Gamut
92% (DCI-P3, CIE 1976)
Operation Hour
16/7

Haze
2%
Display
Dynamic C/R
MEGA
H-Scanning Frequency
30 ~ 81kHZ
V-Scanning Frequency
48 ~ 75HZ
Maximum Pixel Frequency
594MHz
Sound
Speaker Type
Built in Speaker(10W + 10W)
Connectivity
Input
RGB
DVI-D
Video
HDMI 2.0 (2)

HDCP
HDCP 2.2
Audio
Stereo Mini Jack, DVI/HDMI/Audio(Common)
USB
USB 2.0 x 2
Output
Audio
Stereo Mini Jack
External Control
RS232C(in/out) thru stereo jack, RJ45

External Sensor
IR
Power
Type
Internal
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Max[W/h]
198

Typical[W/h]
143

Rating[W/h]
180
BTU(Max)
675.2
Sleep mode
0.5
Mechanical Specification
Dimension (mm)
Set
1897.8 x 1080.8 x 56.7
Package
2090 x 1247 x 260
Weight (kg)
Set
48.4
Package
63.7
VESA Mount (mm)
600 X 400
Bezel Width (mm)
10.9mm(U/L/R), 12.9mm(B)
Operation
Operating Temperature
0 ℃ ~ 40 ℃

Humidity
10 % ~ 80 %
Feature
Key Features
UHD Signage Display Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0

Orientation
N/A

Remote Control
N/A
Special Features
H/W: Temperature Sensor,Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W 2ch), IP5x Rating, Wi-Fi/BT S/W: Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting)
Internal Player
Processor
Cortex A72 1.7GHz Quad-Core CPU

On-Chip Cache Memory
L1 Instruction Cache : 48KB L1 Data Cache : 32K L2 Cache : 2MB

Clock Speed
1.7GHz

Main Memory Interface
2.5GB LPDDR4 1.5GHz 64bit
Graphics
Graphic resolution : 1920x1080 Output resolution : 3840x2160 (Scale up from graphic processing result.)

Storage (FDM)
8GB (3.88GB Occupied by O/S, 4.12GB Available)

Multimedia
*Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG

IO Ports
USB 2.0
Operating System
Tizen 4.0 (VDLinux)
Certification
Safety
60950-1

EMC
Class A

Security
802.1x(WPA2 Enterprise) ('20.1~) : EAP-TLS, EAP-TTLS, EAP-PEAP
Accessory
Included
Quick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries
