Panel
Diagonal Size
85"

Type
Direct LED BLU
Resolution
3840*2160 (4K UHD)

Pixel Pitch(mm)
0.4875 x 0.4875
Active Display Area(mm)
1872(H) x 1053(V)
Brightness(Typ.)
300 nit

Contrast Ratio
4000:1
Viewing Angle(H/V)
178/178

Response Time(G-to-G)
8ms (Typ.)
Display Colors
16.7M(True Display)
Color Gamut
(NTSC) 72%
Operation Hour
16/7

Haze
2%
Display
Dynamic C/R
MEGA
H-Scanning Frequency
30 ~ 81kHZ
V-Scanning Frequency
48 ~ 75HZ
Maximum Pixel Frequency
594MHz
Sound
Speaker Type
Built in Speaker(10W + 10W)
Connectivity
Input
RGB
-
Video
HDMI 2.0 (2)

HDCP
HDCP 2.2
Audio
Stereo Mini Jack, HDMI/Audio(Common)
USB
USB 2.0 x 1
Output
Audio
Stereo Mini Jack
External Control
RS232C(in) thru stereo jack, RJ45
Power
Type
Internal
Power Supply
AC 100 - 240 V, 50/60 Hz
Power Consumption
Max[W/h]
273.0

Typical[W/h]
208.0

Rating[W/h]
248.0
BTU(Max)
930.9
Sleep mode
0.5
Mechanical Specification
Dimension (mm)
Set
1900.9 x 1086.2 x 26.9
Package
2075 x 1237 x 220
Weight (kg)
Set
41.5
Package
54.3
VESA Mount (mm)
600*400
Stand Type
No
Bezel Width (mm)
3 Bezel-less
Operation
Operating Temperature
0 ℃ ~ 40 ℃

Humidity
10.0 % ~ 80.0 %
Feature
Key Features
UHD Signage with Built-in MagicInfo Lite

Orientation
Landscape

Remote Control
N/A
Special Features
H/W : Temperature Sensor,Clock Battery(168hrs Clock Keeping), Built in Speaker(10W 2ch), IP5x Rating S/W : Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting)
Internal Player
Processor
Cortex A72 1.7GHz Quad-Core CPU

On-Chip Cache Memory
L1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB

Clock Speed
1.7GHz

Main Memory Interface
2.0GB LPDDR4 1.5GHz 64bit
Graphics
Graphic resolution : 1920x1080 Output resolution : 3840x2160 (Scale up from graphic processing result.)

Storage (FDM)
8GB (3.88GB Occupied by O/S, 4.12GB Available)

Multimedia
*Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG

IO Ports
USB 2.0
Operating System
Tizen 4.0 (VDLinux)
Certification
Safety
60950-1

EMC
Class B

Security
-
Accessory
Included
Quick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries
Optional
Stand
N/A

Mount
WMN8200SG (Land Only)

Specialty
N/A
Media Player
Media Player
Media Player
N/A
