Monitor Samsung SMART Signage SL46B

OTRZYMAJ RABAT DODATKOWY NAWET 40%* W każdej chwili możesz się wypisać
Zapisując się do Newslettera, otrzymasz RABAT do 40%* Możesz wypisać się w każdej chwili
Pola wymagane
Cena na telefon

Zapytanie o produkt Monitor Samsung SMART Signage SL46B

TokenZmień
Pola wymagane
Produkt niedostępny

Negocjuj cenę

TokenZmień
Pola wymagane
downloadPobierz kartę produktu

TECH SPECS

Display

  • H-Scanning Frequency

    30 - 81 KHz

  • Maximum Pixel Frequency

    148.5 MHz

  • V-Scanning Frequency

    48 - 75 Hz

Panel

  • Diagonal Size

    46"

  • Type

    S-PVA

  • Resolution

    1,920 x 1,080

  • Pixel Pitch(mm)

    0.53025 (H) x 0.53025 (V) mm

  • Active Display Area

    1,018.08 (H) X 572.67 (V) mm

  • Brightness (Typical)

    1,500 cd/㎡

  • Contrast Ratio (Dynamic)

    10,000:1

  • Viewing Angle (H/V)

    178 / 178 ° (CR > 10)

  • Response Time (G-to-G)

    8 ms

  • Display Colour

    16.7 M

  • Colour Gamut

    72 %

  • Contrast Ratio

    4,000:1


Connectivity

  • Input

    RGB
    D-SUB, DVI-D
    Video
    USB, HDMI, CVBS, Component (by D-SUB)
    Audio
    RCA(L/R) , Stereo Mini Jack

  • Output

    RGB
    DVI-D (Loop-out)
    Video
    N/A
    Audio
    Stereo Mini Jack
    Power Out
    N/A

  • External Control

    RJ45, RS232C (In/Out)

  • External Sensor

    Attached

Mechanical Specification

  • Dimension

    Set Dimension (WxHxD)
    1,049.4 x 602.6 x 125 mm
    Package Dimension (WxHxD)
    1,145 x 726 x 300 mm

  • Weight

    Set Weight
    26.8 kg
    Package Weight
    32.6 kg

  • VESA Mount

    600 x 400mm

  • Protection Glass

    N/A

  • Stand Type

    N/A

  • Media Player Option Type

    Embedded, SIM (Slide in Module )

Operation

  • Operating Temperature

    0℃ - 30℃(Direct Sunlight)

  • Humidity

    10 - 80 %

General Features

  • Key

    Extremely High Brightness

  • Special

    Plug and Play, MagicInfo Lite, Slide in Module, Digital Daisy Chains, Built in Speakers, Lamp Error Detection, Anti Image Retention, Temperature Sensor, RS232C/RJ45 MDC, PIP/PBP, Video Wall(10x10), Pivot Display, Button Lock, Smart Scheduling

Power

  • Energy Efficiency Class

    N/A

  • Power Supply

    AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

  • Power Consumption

    Off Mode
    Less than 1 W
    On Mode
    440 W (Max) / 356 W (Typ)
    Sleep Mode
    Less than 1 W

  • Type

    Internal

Embedded PC

  • CPU

    N/A

  • N/B

    N/A

  • S/B

    N/A

  • GPU

    N/A

  • FDM/HDD

    N/A

  • Memory

    N/A

  • Ethernet

    N/A

  • Connectivity

    USB
    N/A
    Output
    N/A
    Others
    N/A

Certification

  • EMC

    FCC (USA) FCC Part 15, Subpart B class A CE (Europe) EN55022, EN55024 VCCI (Japan) V-3 (CISPR22) KCC (Korea) :KN22, KN24 BSMI (Taiwan) : CNS13438 (CISPR22) C-Tick (Australia) : AS/NZS3548 (CISPR22) CCC(China) :GB 9254-2008, GB 17625.1-2003

  • Environment

    N/A

  • Safety

    UL (USA) : UL 60950-1 CSA (Canada) : CSA C22.2 No. 60950-1 TUV (Germany) : EN60950-1 NEMKO (Norway) : EN60950-1 KC (Korea) : K60950-1 CCC (China) : GB 4943-2001 PSB (Singapore) : IEC60950-1 GOST (Russia) : IEC60950-1, EN55022 SIQ (Slovenia) : IEC60950-1, EN55022 PCBC (Poland) : IEC60590-1, EN55022 NOM (Mexico) : NOM-019-SCFI-1993 IRAM (Argentina) :IEC60950-1 SASO (Saudi Arabia) : IEC60950-1

Accessory

  • Included

    Quick Setup Guide, Warranty Card, Application CD, Power Cord, Remote Controller, Batteries, D-Sub Cable

  • Optional

    Mount
    N/A
    Specialty
    N/A
    Stand
    N/A
