Panel
Diagonal Size
46"

Type
IPS
Resolution
1920*1080 (Full HD)

Pixel Pitch(mm)
0.53x0.53 mm
Active Display Area(mm)
1018.08(H) x 572.6(V)
Brightness(Typ.)
500 nit

Contrast Ratio
1200:1
Viewing Angle(H/V)
178/178

Color Gamut
72%
Operation Hour
24/7

Haze
25%
Connectivity
Input
Video
HDMI 2.0 (2) /DVI-D, Display Port 1.2

Audio
Stereo mini Jack
USB
USB 2.0 x 1
Output
Video
DP1.2(Loop-out)
Audio
Stereo mini Jack
External Control
RS232C(in/out), RJ45 in
Power
Power Supply
AC 100 - 240 V, 50/60 Hz
Power Consumption
Max[W/h]
160

Typical[W/h]
128

Sleep mode
less than 0.5W
Mechanical Specification
Dimension (mm)
Set
1022 x 577 x 69.9 mm
Package
1193 x 719 x 257 mm
Weight (kg)
Set
15.7 kg
Package
22.2 kg
VESA Mount (mm)
600 x 400
Bezel Width (mm)
2.25mm(U/L), 1.25mm(R/B)
Operation
Operating Temperature
0 ℃ ~ 40 ℃

Humidity
10 % ~ 80 %
Feature
Key Features
Ultra Narrow Bezel

Orientation
Landscape / Portrait

Remote Control
N/A
Special Features
H/W : Temperature Sensor, Video Wall Daisy Chain(10x10), DP 1.2 Digital Daisy Chain(Supporting UHD Resolution, HDCP support), Clock Battery(168hrs Clock Keeping) // S/W : Auto Source Switching & Recovery, RS232C/RJ45 MDC, Button Lock, Smart F/W update
Internal Player
Processor
N/A

On-Chip Cache Memory
N/A

Clock Speed
N/A

Main Memory Interface
N/A
Graphics
N/A

Storage (FDM)
N/A

Multimedia
N/A

IO Ports
N/A
Operating System
N/A
Certification
Safety
60950-1

EMC
Class A

IP Rating
IP5x
Accessory
Included
Quick Setup Guide, Warranty Card, Power Cord, RS232C(IN) Gender (Stereo to DB-9), Remote Controller + Batteries, DP cable
Optional
Stand
N/A

Mount
WMN-46VD

Specialty
N/A
Media Player
Media Player
Media Player
N/A
