Panel
Diagonal Size
55"

Type
IPS
Resolution
1920*1080 (Full HD)

Pixel Pitch(mm)
0.63x0.63
Active Display Area(mm)
1209.6(H) x 680.4(V)
Brightness(Typ.)
500 nit

Contrast Ratio
1000:1
Viewing Angle(H/V)
178/178

Color Gamut
72%
Operation Hour
24/7

Haze
28%
Connectivity
Input
Video
HDMI 2.0 (2) /DVI-D, Display Port 1.2

HDCP
HDCP2.2
Audio
Stereo mini Jack
USB
USB 2.0 x 1
Output
Video
DP1.2(Loop-out)
Audio
Stereo mini Jack
External Control
RS232C(in/out), RJ45 in
Power
Power Supply
AC 100 - 240 V, 50/60 Hz
Power Consumption
Max[W/h]
220.0

Typical[W/h]
133.0

Sleep mode
less than 0.5W
Mechanical Specification
Dimension (mm)
Set
1212.2 x 683 x 70.4
Package
1398 x 844 257
Weight (kg)
Set
19.5
Package
28.6
VESA Mount (mm)
600 x 400
Bezel Width (mm)
B2B : 1.74mm (Panel Bezel to Panel Bezel), 1.3mm(U/L), 0.44mm(R/B) A2A : 2.49mm (Active area to Active area), 1.75mm(U/L), 0.74mm(R/B)
Operation
Operating Temperature
0 ℃ ~ 40 ℃

Humidity
10.0 % ~ 80.0 %
Feature
Key Features
Extreme Narrow Bezel

Orientation
Landscape / Portrait

Remote Control
N/A
Special Features
H/W : ACM Support(Advanced Color Management) Temperature Sensor Video Wall Daisy Chain(10x10) DP 1.2 Digital Daisy Chain(Supporting UHD Resolution, HDCP support) Clock Battery(168hrs Clock Keeping) S/W : Auto Source Switching & Recovery RS232C/RJ45 MDC Button Lock Smart F/W update
Internal Player
Processor
N/A

On-Chip Cache Memory
N/A

Clock Speed
N/A

Main Memory Interface
N/A
Graphics
N/A

Storage (FDM)
N/A

Multimedia
N/A

IO Ports
N/A
Operating System
N/A
Certification
Safety
60950-1

EMC
Class B

IP Rating
IP5x
Accessory
Included
Quick Setup Guide Warranty Card Power Cord RS232C(IN) Gender (Stereo to DB-9) Remote Controller + Batteries DP cable
Optional
Stand
N/A

Mount
WMN-55VD

Specialty
N/A
Media Player
Media Player
Media Player
N/A
