Dane techniczne

Panel

Diagonal Size82"

Type120Hz Edge

Resolution3840*2160 (4K UHD)

Pixel Pitch(mm)0.15675 x 0.047025

Active Display Area(mm)1805.76(H) x 1015.74(V)

Brightness(Typ.)300 nit

Contrast Ratio5000:1

Viewing Angle(H/V)178/178

Response Time(G-to-G)6ms (Max 15ms)

Display Colors16.7M

Color Gamut0.72

HazeN/A

Display

Dynamic C/RMEGA

H-Scanning Frequency30 ~ 81kHZ

V-Scanning Frequency48 ~ 75HZ

Maximum Pixel Frequency594MHz

Sound

Speaker TypeBuilt in Speaker(10W 2CH + 20W Woofer)

Connectivity

Input

RGBDVI-D

VideoHDMI 2.0 (2)

HDCPN/A

AudioStereo Mini Jack, DVI/HDMI/Audio(Common)

USBN/A

Output

RGBN/A

VideoN/A

AudioStereo Mini Jack

Power OutN/A

External ControlRS232C(in/out) thru stereo jack, RJ45

External SensorN/A

TunerN/A

Power

TypeInternal

Power SupplyAC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption

Max[W/h]325

Typical[W/h]237

BTU(Max)295

Sleep modeless than 0.5W

Off modeless than 0.5W

Mechanical Specification

Dimension (mm)

Set1830.0 x 1054.0 x 60.9 / 1830.0 x 1144.6 x 387.2 (with Stand)

Package2017 x 1222 x 295

Weight (kg)

Set44.4 kg

Package60.4 kg

VESA Mount (mm)600*400

Mounting HoleN/A

Protection GlassN/A

Stand TypeFoot Stand (Inbox)

Media Player Option TypeN/A

Bezel Width (mm)3 Bezel-less

Operation

Recommended Usage Hours16/7

Operating TemperatureN/A  ℃  ~   N/A   ℃

Humidity10.0  %  ~   80.0   %

Feature

Key FeaturesUHD Signage Display Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0

Special FeaturesHW : Built in Speaker(10W 2ch + 20W Woofer), Wi-Fi SW : Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting)

Internal Player

ProcessorCoretex A72 1.7GHz Quad-Core CPU

On-Chip Cache MemoryL1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB

Clock Speed1.7GHz

Main Memory Interface2.5GB LPDDR4 1.5GHz 64bit

GraphicsGraphic resolution : 1920x1080 Output resolution : 3840x2160 (Scale up from graphic processing result.)

Storage (FDM)8GB (3.88GB Occupied by O/S, 4.12GB Available)

Multimedia*Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG

IO PortsUSB 2.0

Operating SystemTizen 4.0 (VDLinux)

Certification

SafetyCB (Europe) : IEC60065/EN60065KC(Korea) : K 60065RCM(Australia) : IEC60065/AS/NZS 60065TUV (Germany) : CENEMKO (Norway) : CE

EMCClass A

Accessory

IncludedQuick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries

Optional

StandN/A (Inbox)

MountWMN8000SXK

SpecialtyN/A

Media Player

Media Player

Media PlayerN/A
