Strona głównaMONITORY MULTIMEDIALNESAMSUNGMonitor zewnętrzny Samsung SMART Signage OH46F (LH46OHFPKBC/EN)
Samsung

Monitor zewnętrzny Samsung SMART Signage OH46F (LH46OHFPKBC/EN)

OTRZYMAJ RABAT DODATKOWY NAWET 40%* W każdej chwili możesz się wypisać
Zapisując się do Newslettera, otrzymasz RABAT do 40%* Możesz wypisać się w każdej chwili
Pola wymagane
Cena na telefon

Zapytanie o produkt Monitor zewnętrzny Samsung SMART Signage OH46F (LH46OHFPKBC/EN)

TokenZmień
Pola wymagane
Produkt niedostępny

Negocjuj cenę

TokenZmień
Pola wymagane
downloadPobierz kartę produktu

Panel

  • Diagonal Size46"
  • TypeS-VA
  • Resolution1920*1080 (Full HD)
  • Pixel Pitch(mm)0.53mm(H) X 0.53mm(V)
  • Active Display Area(mm)1018.08(H) x 572.67(V)
  • Brightness(Typ.)2500 nit
  • Contrast Ratio5000:1
  • Viewing Angle(H/V)178/178 (TBD)
  • Response Time(G-to-G)6ms
  • Display Colors8 bit - 16.7M
  • Color Gamut72%
  • Haze0%

Display

  • Dynamic C/R100,000:1
  • H-Scanning Frequency108 ~ 139.5 kHZ
  • V-Scanning Frequency96 ~ 123 Hz
  • Maximum Pixel Frequency297MHz

Sound

  • Speaker TypeN/A

Connectivity

Input
  • RGBN/A
  • VideoHDMI 1.4 (2), HDBaseT(LAN Common)
  • AudioN/A
  • UsbUSB 2.0 x 1
Output
  • RGBN/A
  • VideoN/A
  • AudioStereo Mini Jack
  • Power OutN/A
  • External ControlRS232C (In/Out), RJ45(In/Out), HDBaseT
  • External SensorN/A
  • TunerN/A

Power

  • TypeInternal
  • Power SupplyAC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
  • Max[W/h]TBD
  • Typical[W/h]TBD
  • BTU(Max)TBD
  • Sleep modeTBD
  • Off modeTBD

Mechanical Specification

Dimension (mm)
  • Set1069.0 x 623.6 x 85.0 mm
  • Package1156 x 713 x 200 mm
Weight (kg)
  • Set40.5Kg
  • Package44.3Kg
  • VESA Mount (mm)N/A
  • Protection GlassYes (5T Tempered Glass)
  • Stand TypeN/A
  • Media Player Option TypeN/A
  • Bezel Width (mm)24.9 / 24.9 / 24.9 / 24.9 mm

Operation

  • Recommended Usage Hours24/7
  • Operating Temperature -30.0  ℃  ~   50.0   ℃
  • Humidity 10.0  %  ~   80.0   %

Feature

  • Key FeaturesPower-box Integrated, IP56 Outdoor, Built-in MagicInfo Player S4, SSSP 4.0
  • Special Features IP56 Certified for Simple Enclosure Outdoor,
    Protection Glass(IK-10 Level, Anti Graffiti, Infrared Reduce),
    Polarized Sun Glasses Viewable in any direction, HD Base T for Long Distance Installalling, Portrait /Landscape Installation Support, Lamp Error Detection, Auto Brightness Control with Ambient Brightness Sensor, Temperature Sensor, RJ45 MDC, Auto Source Switching & Recovery, Clock Battery(80hrs Clock Keeping), Kensington Lock
Internal Player
  • ProcessorCortex-A12 1.3GHz Quad Core CPU
  • On-Chip Cache MemoryL1 (I/D) : 32KB / 32KB L2 (Unified) : 1MB
  • Clock Speed1.3GHz CPU Quad
  • Main Memory Interface2.5GB 3 channel 96bit DDR3-933 (1866MHz)
  • Graphics2D & 3D Graphics Engine - Up to 3840x2160p. 32bpp - Supports OpenGL ES
  • Storage (FDM)8GB (3.75GB Occupied by O/S, 4.25GB Available, )
  • MultimediaVideo Decoder - MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC - VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 Audio DSP (Decoder) - AC3 (DD), MPEG, DTS and etc.
  • IO PortsUSB 2.0
  • Operating SystemTizen 2.4 (VDLinux)

Certification

  • SafetyCB : IEC60950-1/EN60950-1 (EN) UL : cUL60950-1 (GO)
  • EMCCE : EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003 (EN) FCC : Part 15, Subpart B Class A (GO)
  • EnvironmentN/A

Accessory

  • IncludedQuick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote Controller, Batteries
Optional
  • StandN/A
  • Mount N/A
  • SpecialtyN/A

Media Player

Media Player
  • Media PlayerN/A
