Panel
Diagonal Size
55"

Type
120Hz E-LED BLU
Resolution
1920*1080 (Full HD)

Pixel Pitch(mm)
0.630 x 0.630
Active Display Area(mm)
1209.60(H) x 680.40(V)
Brightness(Typ.)
3500(peak 4,000) nit

Contrast Ratio
5000:1
Viewing Angle(H/V)
178/178

Response Time(G-to-G)
8ms
Display Colors
8 bit - 16.7M
Color Gamut
72%
Operation Hour
24/7

Haze
0%
Display
Dynamic C/R
100,000:1
H-Scanning Frequency
26~136kHz(HDMI)
V-Scanning Frequency
24~75Hz(HDMI)
Maximum Pixel Frequency
594MHz
Connectivity
Input
Video
HDMI 2.0 (2), HDBaseT(LAN Common)

HDCP
HDCP 2.2
USB
USB (1)
Output
Audio
Stereo Mini Jack
External Control
RS232C (In/Out), RJ45(In/Out), HDBaseT
Power
Type
Internal
Power Supply
AC 100 - 240 V, 50/60 Hz
Power Consumption
Max[W/h]
530

Typical[W/h]
EU 274, US 159

BTU(Max)
1809
Sleep mode
Less than 0.5W
Off mode
Less than 0.5W
Mechanical Specification
Dimension (mm)
Set
1260.6 x 731.4 x 85.0 mm
Package
1358 x 845 x 230 mm
Weight (kg)
Set
46.1 kg
Package
52.6 kg
Protection Glass
Yes (5T Tempered Glass)
Bezel Width (mm)
24.9 / 24.9 / 24.9 / 24.9 mm
Operation
Operating Temperature
-30 ℃ ~ 50 ℃

Humidity
10 % ~ 100 %
Feature
Key Features
Power-box Integrated, IP56 Outdoor,Built-in MagicInfo Player S6, SSSP 6.0

Orientation
Landscape / Portrait

Remote Control
N/A
Special Features
IP56 Rated Simple Enclosure Outdoor, Protection Glass(IK-10 Level, Anti Graffiti, Infrared Reduce), Polarized Sun Glasses Viewable in any direction, HD Base T for Long Distance Installalling, Portrait /Landscape Installation Support, Lamp Error Detection, Auto Brightness Control with Ambient Brightness Sensor, Temperature Sensor, RJ45 MDC, Auto Source Switching & Recovery, Clock Battery(80hrs Clock Keeping), Kensington Lock
Internal Player
Processor
Cortex A72 1.7GHz Quad-Core CPU

On-Chip Cache Memory
L1 Instruction Cache : 48KB / L1 Data Cache : 32KB / L2 Cache : 2MB

Clock Speed
1.7GHz

Main Memory Interface
2.5GB / LPDDR4 1.5GHz 64bit
Graphics
Graphic resolution : 1920x1080 / Output resolution : 1920x1080 - Supports OpenGL ES

Storage (FDM)
8GB (3.88GB Occupied by O/S, 4.12GB Available)

Multimedia
Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC / VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 Audio Decoder : AC3 (DD), MPEG

IO Ports
USB 2.0
Operating System
Tizen 4.0 (VDLinux)
Certification
Safety
60950-1

EMC
Class A

IP Rating
IP56
Accessory
Included
Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote Controller, Batteries
Optional
Stand
N/A

Mount
N/A

Specialty
N/A
Media Player
Media Player
Media Player
N/A
