Panel

  • Diagonal Size75"
  • Resolution1920*1080 (Full HD)
  • Pixel Pitch(mm)0.860 x 0.860
  • Active Display Area(mm)1650.24(H) x 928.26(V)
  • Brightness(Typ.)2500 nit
  • Contrast Ratio5000:1
  • Viewing Angle(H/V)178/178
  • Display Colors8 bit - 16.7M
  • Color Gamut72%
  • Haze0%

Display

  • Dynamic C/R100,000:1
  • H-Scanning Frequency108 ~ 139.5 kHZ
  • V-Scanning Frequency96 ~ 123 Hz
  • Maximum Pixel Frequency297MHz

Sound

  • Speaker TypeN/A

Connectivity

Input
  • RGBN/A
  • VideoHDMI 1.4 (2), HDBaseT(LAN Common)
  • HDCPHDCP 2.2
  • AudioN/A
  • USBUSB 2.0 (1)
Output
  • RGBN/A
  • VideoN/A
  • AudioStereo Mini Jack
  • Power OutN/A
  • External ControlRS232C (In/Out), RJ45(In/Out), HDBaseT
  • External SensorN/A
  • TunerN/A

Power

  • TypeInternal
  • Power SupplyAC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
  • Max[W/h]1,400
  • Typical[W/h]W/W(EU) 520, US/KOR/Etc. TBD (※ Etc: China, Taiwan, Bra, CIS)
  • BTU(Max)4774
  • Sleep modeless than 0.5W
  • Off modeless than 0.5W

Mechanical Specification

Dimension (mm)
  • Set1774.8 X 1053.4 X 120
  • Package1946 x 1252 x 495
Weight (kg)
  • Set142 kg
  • Package188 kg
  • VESA Mount (mm)N/A
  • Mounting Hole870 x 1118.4 (M8 x 8Hole)
  • Protection GlassYes (5T Tempered Glass)
  • Stand TypeN/A
  • Media Player Option TypeN/A
  • Bezel Width (mm)59.8 / 59.8 / 59.8 / 59.8 mm

Operation

  • Recommended Usage Hours24/7
  • Operating Temperature -30.0  ℃  ~   50.0   ℃
  • Humidity 10.0  %  ~   80.0   %
  • IP Certificate IP56

Feature

  • Key FeaturesHeat Exchanger, IP56 Certified, Built-in MagicInfo Player S4, SSSP 4.0
  • Special Features IP56 Certified for Simple Enclosure Outdoor, Protection Glass(IK-10 Level, Anti Graffiti, Infrared Reduce), Polarized Sun Glasses Viewable in any direction, HD Base T for Long Distance Installalling, Portrait /Landscape Installation Support, Lamp Error Detection, Auto Brightness Control with Ambient Brightness Sensor, Temperature Sensor, RJ45 MDC, Auto Source Switching & Recovery, Clock Battery(80hrs Clock Keeping), Kensington Lock
Internal Player
  • ProcessorCortex-A12 1.3GHz Quad Core CPU
  • On-Chip Cache MemoryL1 (I/D) : 32KB / 32KB L2 (Unified) : 1MB
  • Clock Speed1.3GHz CPU Quad
  • Main Memory Interface2.5GB 3 channel 96bit DDR3-933 (1866MHz)
  • Graphics2D & 3D Graphics Engine - Up to 3840x2160p. 32bpp - Supports OpenGL ES
  • Storage (FDM)8GB (3.75GB Occupied by O/S, 4.25GB Available, )
  • MultimediaVideo Decoder - MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC - VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 Audio DSP (Decoder) - AC3 (DD), MPEG, DTS and etc.
  • IO PortsUSB 2.0
  • Operating SystemTizen 2.4 (VDLinux)

Certification

  • SafetyCB (Europe) : IEC60950-1/EN60950-1 CCC (China) : GB4943.1-2011 PSB (Singapore) : PSB+IEC60950-1 NOM (Mexico) : NOM-001-SCFI-1993 IRAM (Argentina) : IRAM+IEC60950-1 SASO (Saudi Arabia) : SASO+IEC60950-1 BIS(India) : IEC60950-1 / IS13252 NOM(Mexico) : NOM-019-SCFI-1998 KC(Korea) : K 60950-1 EAC(Russia) : EAC+IEC60950-1 INMETRO(Brazil) : INMETRO+IEC60950-1 BSMI(Taiwan) : BSMI+IEC60950-1 RCM(Australia) : IEC60950-1/AS/NZS 60950-1 UL(USA) : cUL60950-1 CSA (Canada) : cUL TUV (Germany) : CE NEMKO (Norway) : CE
  • EMCFCC (USA) Part 15, Subpart B Class A CE (Europe) : EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003 VCCI (Japan) : VCCI V-3 /2010.04 Class A KCC/EK (Korea) : KN22 / 24 BSMI (Taiwan) : CNS13438 (ITE EMI) Class A / CNS13439 (AV EMI) / CNS14409 (AV EMS) / CNS14972 (Digital) C-Tick (Australia) : AS/NZS CISPR22:2009 CCC(China) :GB9254-2008 GB17625.1-2012 GOST(Russia/CIS) : GOST R 51317 Series, GOST 22505-97 EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003

Accessory

  • IncludedQuick Setup Guide, Regulatory Guide, Warranty Card, Remote Controller, Batteries
Optional
  • StandN/A
  • Mount N/A
  • SpecialtyN/A

Media Player

Media Player
  • Media PlayerN/A
