Monitor zewnętrzny Samsung SMART Signage OH85F (LH85OHFPLBC/EN)
OTRZYMAJ RABAT DODATKOWY NAWET 40%* W każdej chwili możesz się wypisać
Cena na telefon
Panel
- Diagonal Size85"
- Resolution3840*2160 (4K UHD)
- Pixel Pitch(mm)0.488mm(H) X 0.488mm(V)
- Active Display Area(mm)1872(H) x 1053(V)
- Brightness(Typ.)2500 nit
- Contrast Ratio3000:1
- Viewing Angle(H/V)178/178
- Display Colors10 bit - 1.07B
- Color Gamut72%
- Haze0%
Display
- Dynamic C/R100,000:1
- H-Scanning Frequency30~135kHz (DP), 30~90kHz (HDMI)
- V-Scanning Frequency30~75Hz (DP), 24~75Hz (HDMI)
- Maximum Pixel Frequency533.25MHz (DP), 297MHz (HDMI)
Sound
- Speaker TypeN/A
Connectivity
Input
- RGBDP 1.2 (2) @UHD 60Hz
- VideoHDMI 1.4 (2) @UHD 30Hz, HDBaseT
- HDCPHDCP 1.4
- AudioN/A
- USBUSB 2.0 (1) (only for FW update)
Output
- RGBN/A
- VideoHDMI 1.4 (2) @UHD 30Hz, HDBaseT
- AudioStereo Mini Jack
- Power OutN/A
- External ControlRS232C (In), RJ45, HDBaseT
- External SensorN/A
- TunerN/A
Power
- TypeInternal
- Power SupplyAC 100 - 240 V (+/- 10 %), 50/60 Hz
Power Consumption
- Max[W/h]1,600
- Typical[W/h]W/W(EU) 680 US/KOR/Etc. TBD ※ Etc: CHINA, TAIWAN, BRA, CIS
- BTU(Max)5,456
- Sleep modeless than 0.5W
- Off modeless than 0.5W
Mechanical Specification
Dimension (mm)
- Set2004 X 1185 X 120
- Package2175 x 1383 x 495
Weight (kg)
- Set163kg
- Package211kg
- VESA Mount (mm)N/A
- Mounting Hole1000 x 1118.4 (M8 x 8Hole)
- Protection GlassYes (5T Tempered Glass)
- Stand TypeN/A
- Media Player Option TypeN/A
- Bezel Width (mm)62 / 62 / 62 / 62 mm
Operation
- Recommended Usage Hours24/7
- Operating Temperature -30.0 ℃ ~ 50.0 ℃
- Humidity 10.0 % ~ 80.0 %
- IP Certificate IP56
Feature
- Key FeaturesSlim High Brightness, IP56 Certified, Heat Exchanger
- Special Features IP56 Certified for Simple Enclosure Outdoor, Protection Glass(IK-10 Level, Anti Graffiti, Infrared Reduce), Polarized Sun Glasses Viewable in any direction, HD Base T for Long Distance Installalling, Portrait /Landscape Installation Support, Lamp Error Detection, Auto Brightness Control with Ambient Brightness Sensor, Temperature Sensor, RJ45 MDC, FHD 4-PBP, Auto Source Switching & Recovery, Clock Battery(80hrs Clock Keeping)
Internal Player
- ProcessorN/A
- On-Chip Cache MemoryN/A
- Clock SpeedN/A
- Main Memory InterfaceN/A
- GraphicsN/A
- Storage (FDM)N/A
- MultimediaN/A
- IO PortsN/A
- Operating SystemN/A
Certification
- SafetyCB (Europe) : IEC60950-1/EN60950-1 CCC (China) : GB4943.1-2011 PSB (Singapore) : PSB+IEC60950-1 NOM (Mexico) : NOM-001-SCFI-1993 IRAM (Argentina) : IRAM+IEC60950-1 SASO (Saudi Arabia) : SASO+IEC60950-1 BIS(India) : IEC60950-1 / IS13252 NOM(Mexico) : NOM-019-SCFI-1998 KC(Korea) : K 60950-1 EAC(Russia) : EAC+IEC60950-1 INMETRO(Brazil) : INMETRO+IEC60950-1 BSMI(Taiwan) : BSMI+IEC60950-1 RCM(Australia) : IEC60950-1/AS/NZS 60950-1 UL(USA) : cUL60950-1 CSA (Canada) : cUL TUV (Germany) : CE NEMKO (Norway) : CE
- EMCFCC (USA) Part 15, Subpart B Class A CE (Europe) : EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003 VCCI (Japan) : VCCI V-3 /2010.04 Class A KCC/EK (Korea) : KN22 / 24 BSMI (Taiwan) : CNS13438 (ITE EMI) Class A / CNS13439 (AV EMI) / CNS14409 (AV EMS) / CNS14972 (Digital) C-Tick (Australia) : AS/NZS CISPR22:2009 CCC(China) :GB9254-2008 GB17625.1-2012 GOST(Russia/CIS) : GOST R 51317 Series, GOST 22505-97 EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003
Accessory
- IncludedQuick Setup Guide, Regulatory Guide, Warranty Card,Remote Controller, Batteries
Optional
- StandN/A
- Mount N/A
- SpecialtyN/A
Media Player
Media Player
- Media PlayerN/A
