Strona głównaMONITORY MULTIMEDIALNESAMSUNGMonitor zewnętrzny Samsung SMART Signage OH85F (LH85OHFPLBC/EN)
Samsung

Monitor zewnętrzny Samsung SMART Signage OH85F (LH85OHFPLBC/EN)

OTRZYMAJ RABAT DODATKOWY NAWET 40%* W każdej chwili możesz się wypisać
Zapisując się do Newslettera, otrzymasz RABAT do 40%* Możesz wypisać się w każdej chwili
Pola wymagane
Cena na telefon

Zapytanie o produkt Monitor zewnętrzny Samsung SMART Signage OH85F (LH85OHFPLBC/EN)

TokenZmień
Pola wymagane
Produkt niedostępny

Negocjuj cenę

TokenZmień
Pola wymagane
downloadPobierz kartę produktu

Panel

  • Diagonal Size85"
  • Resolution3840*2160 (4K UHD)
  • Pixel Pitch(mm)0.488mm(H) X 0.488mm(V)
  • Active Display Area(mm)1872(H) x 1053(V)
  • Brightness(Typ.)2500 nit
  • Contrast Ratio3000:1
  • Viewing Angle(H/V)178/178
  • Display Colors10 bit - 1.07B
  • Color Gamut72%
  • Haze0%

Display

  • Dynamic C/R100,000:1
  • H-Scanning Frequency30~135kHz (DP), 30~90kHz (HDMI)
  • V-Scanning Frequency30~75Hz (DP), 24~75Hz (HDMI)
  • Maximum Pixel Frequency533.25MHz (DP), 297MHz (HDMI)

Sound

  • Speaker TypeN/A

Connectivity

Input
  • RGBDP 1.2 (2) @UHD 60Hz
  • VideoHDMI 1.4 (2) @UHD 30Hz, HDBaseT
  • HDCPHDCP 1.4
  • AudioN/A
  • USBUSB 2.0 (1) (only for FW update)
Output
  • RGBN/A
  • VideoHDMI 1.4 (2) @UHD 30Hz, HDBaseT
  • AudioStereo Mini Jack
  • Power OutN/A
  • External ControlRS232C (In), RJ45, HDBaseT
  • External SensorN/A
  • TunerN/A

Power

  • TypeInternal
  • Power SupplyAC 100 - 240 V (+/- 10 %), 50/60 Hz
Power Consumption
  • Max[W/h]1,600
  • Typical[W/h]W/W(EU) 680 US/KOR/Etc. TBD ※ Etc: CHINA, TAIWAN, BRA, CIS
  • BTU(Max)5,456
  • Sleep modeless than 0.5W
  • Off modeless than 0.5W

Mechanical Specification

Dimension (mm)
  • Set2004 X 1185 X 120
  • Package2175 x 1383 x 495
Weight (kg)
  • Set163kg
  • Package211kg
  • VESA Mount (mm)N/A
  • Mounting Hole1000 x 1118.4 (M8 x 8Hole)
  • Protection GlassYes (5T Tempered Glass)
  • Stand TypeN/A
  • Media Player Option TypeN/A
  • Bezel Width (mm)62 / 62 / 62 / 62 mm

Operation

  • Recommended Usage Hours24/7
  • Operating Temperature -30.0  ℃  ~   50.0   ℃
  • Humidity 10.0  %  ~   80.0   %
  • IP Certificate IP56

Feature

  • Key FeaturesSlim High Brightness, IP56 Certified, Heat Exchanger
  • Special Features IP56 Certified for Simple Enclosure Outdoor, Protection Glass(IK-10 Level, Anti Graffiti, Infrared Reduce), Polarized Sun Glasses Viewable in any direction, HD Base T for Long Distance Installalling, Portrait /Landscape Installation Support, Lamp Error Detection, Auto Brightness Control with Ambient Brightness Sensor, Temperature Sensor, RJ45 MDC, FHD 4-PBP, Auto Source Switching & Recovery, Clock Battery(80hrs Clock Keeping)
Internal Player
  • ProcessorN/A
  • On-Chip Cache MemoryN/A
  • Clock SpeedN/A
  • Main Memory InterfaceN/A
  • GraphicsN/A
  • Storage (FDM)N/A
  • MultimediaN/A
  • IO PortsN/A
  • Operating SystemN/A

Certification

  • SafetyCB (Europe) : IEC60950-1/EN60950-1 CCC (China) : GB4943.1-2011 PSB (Singapore) : PSB+IEC60950-1 NOM (Mexico) : NOM-001-SCFI-1993 IRAM (Argentina) : IRAM+IEC60950-1 SASO (Saudi Arabia) : SASO+IEC60950-1 BIS(India) : IEC60950-1 / IS13252 NOM(Mexico) : NOM-019-SCFI-1998 KC(Korea) : K 60950-1 EAC(Russia) : EAC+IEC60950-1 INMETRO(Brazil) : INMETRO+IEC60950-1 BSMI(Taiwan) : BSMI+IEC60950-1 RCM(Australia) : IEC60950-1/AS/NZS 60950-1 UL(USA) : cUL60950-1 CSA (Canada) : cUL TUV (Germany) : CE NEMKO (Norway) : CE
  • EMCFCC (USA) Part 15, Subpart B Class A CE (Europe) : EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003 VCCI (Japan) : VCCI V-3 /2010.04 Class A KCC/EK (Korea) : KN22 / 24 BSMI (Taiwan) : CNS13438 (ITE EMI) Class A / CNS13439 (AV EMI) / CNS14409 (AV EMS) / CNS14972 (Digital) C-Tick (Australia) : AS/NZS CISPR22:2009 CCC(China) :GB9254-2008 GB17625.1-2012 GOST(Russia/CIS) : GOST R 51317 Series, GOST 22505-97 EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003

Accessory

  • IncludedQuick Setup Guide, Regulatory Guide, Warranty Card,Remote Controller, Batteries
Optional
  • StandN/A
  • Mount N/A
  • SpecialtyN/A

Media Player

Media Player
  • Media PlayerN/A
