Display Module Data
Panel Technology TFT LCD
Native Resolution (Pixels) 3840 x 2160
Diagonal Size (inches / cm) 75 / 189,2
Aspect Ratio 16:9
Backlight Technology W-LED / Full Array
Brightness (cd/m2) 600
Contrast Ratio 1200 : 1
Display Colours 1,06 Billion
Response Time (grey to grey avg) ms 8
Viewing Angle (H/V)0 CR >10 178 / 178
Key Specifications
24/7 Operation Certified yes
Local Dimming no
Built in Speakers (W) 10W + 10W
Computer Input - Plug and Play yes
Power Management yes
Cabinet Colour Black
Other HDR Support
Power Supply and Operating Environment
Operating Voltage(ACV) / Frequency(Hz) 100-240 / 50-60
Power Consumption (W) (Operating MAX) 240
Power Consumption (W) (Standby) 0,50
Operating Temperature (oC) 0 - 40
Humidity (%) 20 - 80RH
Weights and Measures
Bezel Size (L/R) mm 19,4/ 19,4
Bezel Size (U/L) mm 19,4 / 19,4
Product Dimensions (W/H/D) mm 1692,5 x 870,7 x 79,8
Product Weight Without Stand (Kg) 34
Installation
Landscape yes
Portrait yes
Horizontal no
Mounting (VESA/Number of Points/Pitch mm) VESA 800 x 400
Connectivity (Audio/Video) INPUT
HDMI 3
VGA 1
Audio 3.5mm Jack 1
Other HDMI2.0 / HDCP 2.2 / CEC
Connectivity (Audio/Video) OUTPUT
Audio RCA R-L 1
Connectivity (Control/Serial Data)
RS232C IN 1
LAN Port 1
USB 1
