DISPLAY
Technology Single-chip DMD
Full 3D features
Resolution Full-HD - 1920 x 1080 pixels
Color wheel: 6 segments RGBCMY
Light source 200W UHP lamp (dimmable 165W)
Brightness(1) up to 2,900 Ansi Lumen (in 2D mode)
INSTALLATION
Lens throw ratio 1.38-2..05:1 (+/- 5%)
Picture size (inches diagonal) 50-180
Aspect ratio 4:3, 16:9, Anamorphic, Letterbox
ELECTRONICS
Horiz. scan freq. 15, 30-102 KHz
Vertic. scan freq. 24-144 Hz
Color System PAL (B,G,H,I,M,N,60);
SECAM;
NTSC 3.58;
NTSC 4.43;
SDTV: 480i/p, 576i/p;
HDTV: 720p, 1080i, 1080p
CONNECTIVITY
Digital 2x HDMI (v.1.4 with Deep Color)
Analog 1x S-Video (miniDIN 4 pin)
1x Composite Video (RCA)
1x Graphic RGBHV (D-sub HD15 pins)
1x Component - YCbCr/RGBs (RCA)
Other 1x RS-232 (D-sub 9 pins)
1x miniUSB (B type - Service)
1x USB (A type - power only)
1x 3D Sync Out
1x Audio OUT
1x 12V 100mA output
GENERAL SPECIFICATIONS
Software control upgradable via RS-232 or mini USB
Power supply 100-240 VAC +/-10%
Power consumption max. 260W
Projector weight 9 kg. / 19.8 lbs
Projector dimensions (WxHxD) 315 x 190 x 315 mm (12.4" x 7.5" x 12.4")
SUPPLIED ACCESSORIES
Quick Start guide and AC cords
SIM2 VISUS Active Glasses (4 pcs.) + emitter
2x HDMI 90 degree adapter
2x remote control (1x black finish, 1x white finish) with batteries
CUBE Ceiling Bracket and extension pole (available in black or white finish)
4+1 pcs PLASTIC ANGULAR BRACKETS
included in the accessory kit - 1 pc spare tilt-adjuster for special installation
OPTIONAL ACCESSORIES
SIM2 VISUS Luxury box (8 additional Active glasses)
SIM2 VISUS SYSTEM Luxury box (7 Active glasses + emitter)
(1) ANSI Lumens specification: This is the typical projector brightness specification found in most sales literature. This measurement allows for direct comparison with other manufacturer's projectors. Measurements are taken in a totally dark test room with brand new lamp at full power, lamp's native white color temperature, internal test pattern (full white) and in compliance with ANSI IT7.228-1997 specification.
