LIGHT ENGINE
DLP® type 1 chip DMD (HD2+ DarkChip2™)
Resolution 1280 x 720 pixels
Lens High quality, high resolution optics with both motorized zoom and focus adj.
Lamp power & life time* 150W 6000 hours
INSTALLATION
Throw ratio 1.8 - 2.4:1 (16:9 mode)
Lens shift V+/-50%
Digital keystone adjustment V+/-18°; H+/-10°
Picture size (inches diagonal) 50-250
Aspect ratio 4:3, 16:9, Anamorphic, LetterBox, panoramic, pixel to pixel + 3 custom-user adjustments
ELECTRONICS
Horiz. & Vert. scan freq. 15-80kHz - 48-100Hz
Video standards (autom. selected) PAL B, G, H, I, M, N, 60; SECAM; NTSC 3,58 & 4,43
HDTV ATSC standards and graphic resolutions USA 480p, 720p, 1080i, 60Hz; EU 576p, 1080i 50Hz.; VGA, SVGA, XGA, SXGA, UXGA (60-85 Hz)
On-board video processing Contrast ratio (Full ON/ Full OFF) >3200:1
Color temperature 3 preset color temp. selectable by OSD + 1 user adjust.
Special adjustments noise reduction, overscan
INPUTS/OUTPUTS
Analog 1 x Composite Video (RCA)
1 x S-Video (mini Din 4 pin)
1 x RGBs/YCrCb (4x RCA)
1 x RGBHV (D-Sub 15 pin)
1 x RS232 (D-Sub 9 pin)
Digital 1 x HDMI™-HDCP
Miscellaneous 1 x OUT digital audio (Toslink)
2 x OUT 12V 100mA on Jack connectors
GENERAL SPECIFICATIONS
Software control upgradable via RS232 serial interface
Power consumption 200W max
Mains voltage range 100-240Vac ±10% (48/62Hz)
Weight 5.0Kg (11 lbs )
Dimensions (WxHxD) 352x174x318 mm (13.9"x6.85"x12.5")
ACCESSORIES
Supplied Installation and User Manual
AC power cords (EU, UK& USA) 6.6 ft (2m)
Remote control and batteries

The DLP® logo and DLP® medallion are trademarks of Texas Instruments.

(*) Lamp life: the hours quoted have been measured in a lab under strict test conditions. Lamp life varies depending on usage conditions and the surrounding environment. The measured lamp life cannot be guaranteed and is not protected by warranty
