Podstawowe parametry:

Typ: DLP
Źródło światła: LED
Rozdzielczość (wyświetlana): Full HD (1920x1080)
Rozdzielczość (podstawowa): Full HD (1920x1080)
Jasność: -/​1200/​- ANSI Lumen (wysoki/​standardowy/​Eco)
Kontrast: 30.000:1
Format obrazu: 16:9 natywny/​4:3 kompatybilny
Przekątna obrazu: 1.65-5.08m
Format projekcji: 1.51:1-2.88:1
Żywotność lampy: 20000/​-/​- godziny (standardowy/​Eco/​Eco+)
Lens-shift: zmotoryzowany, vertikal -60% +60%, poziomo -10% +10%
Złącza wideo: 1x VGA In, 2x HDMI 1.4 In, 1x S-Video, 1x Component (RCA)
Dodatkowe złącza: 2x USB, 1x RS-232
Wymiary (SxWxG): 365x149x441mm
Waga: 12.00kg
Cechy szczególne: 3D-Ready (aktywne)
Specyfikacja:

LIGHT ENGINE

Technology: 1 x chip DMD
Resolution: Full HD 1920 x 1080 pixels
Lighting system: PureLED technology
Special Features: Active 3D(*) visualization
SIM2 DynamicBlack™ Technology enhanced solution (digital)
Contrast ratio (Full ON/OFF): >30,000:1 with DynamicBlack™
Brightness: 1200 lumens (the equivalent of 1,800 lumens(**) of lamp-based projectors)
Expected LED lifetime: 20,000 hours
INSTALLATION

Lens option (throw ratio): 1.51-2.88:1
Motorized Lens shift: V +/-60% /, H +/-10%
Digital keystone adjustment: Vertical
Picture size (inches diagonal): 65-200
Aspect ratio: 4:3, 16:9 Anamorphic, LetterBox, panoramic, pixel to pixel + 3 custom-user adjustments
ELECTRONICS

Horiz. & vertical scan frequency: 15-80kHz/48-144Hz;
Color System: PAL (B,G,H,I,M,N,60); SECAM; NTSC 3.58; NTSC 4.43
PC graphic standards: VGA, SVGA, XGA,SXGA, UXGA, WUXGA
SDTV: 480i/p, 576i/p;
HDTV: 720p 50/60, 1080i 50/60, 1080p 24/50/60 + 576p
INPUTS/OUTPUTS

Analog: 1 x Component - YCbCr/RGBs (RCA)
1 x Graphic RGBHV/YCrCb (1x D-Sub 15 pin)
1x S-Video
Digital: 2 x HDMI (v.1.4 with Deep Color)
Control: 1 x RS-232
1 x USB (B type socket)
1 x USB (Service only)
Miscellaneous: 3D Sync Out
1x 12V 100mA output
1x Video OUT (monitor)
GENERAL SPECIFICATIONS

Software control: upgradable via RS-232 serial interface or USB
Power supply: 100-240 VAC +/-10% (48/62 Hz)
Projector weight: 12 Kg. / 26.5 lbs
Projector dimensions (WxHxD): 365x149x441 mm (14.4"x5.9"x17.4")
ACCESSORIES

Supplied: Installation and user manual
AC power cords
Backlit remote control and batteries
Optional: SIM2 VISUS Active glasses, Emitter (optional)(*)
SIM2 VISUS Active glasses (additional pairs)
SIM2 Universal Ceiling Bracket
(*) A SIM2 3D emitter and glasses pack is required to initiate this feature (sold separately).

(**) Takes into account Helmholtz-Kohlrausch effect where brightness rises with color saturation. LED projectors produce richer and more saturated colors, thus appearing brighter than a lamp-based display with similar measured lumen specifications.

(1) ANSI Lumen Specification: This is the typical projector brightness specification found in most sales literature. This measurement allows for direct comparison with other manufacturer's projectors. Measurements are taken in compliance with ANSI IT7.228-1997 specification.

Due to constant product development, specifications are subject to change without notice.
