LIGHT ENGINE
DLP® Type Single-Chip DMDs 1080p
Resolution 1920x1080 pixels
3D Features (1)
Brightness (2) up to 7,000 ANSI Lumens
Contrast ratio up to 8,000:1
Special features SIM2 Dynamic Black technology
Perfect Fit technology (3)
PureAction 2D/3D for fast action materials
PureMovie 2D
Lamp power 2 x 350W Lamp
Lamp life expectancy (4) 2.000 hours typical in standard power mode; 2.500 hours in ECO mode
INSTALLATION
Lenses Throw ratio M0 lens 0.77:1 (fixed)
M1 lens 1.21-1.45:1
M2 lens (standard lens) 1.45-1.93:1
M3 lens 1.93-3.67:1
Zoom adjustment motorized
Focus adjustment motorized
Optical shift Vertical +60% / -20% motorized
Horizontal +10% / -10% motorized
Digital keystone adjustment (for 2D and 3D 1080p24 modes)
Picture size (inches diagonal) 30-500 inches
Aspect ratio 4:3, 16:9 Anamorphic, LetterBox, Panoramic, Subtitle, Pixel to Pixel + 3 custom-user adjustments
ELECTRONICS
Horizontal & vertical scan freq. 15-120kHz/48-100Hz, 24Hz@1080p
SDTV PAL (B,G,H,I,M,N,60); SECAM; NTSC autom. selected
HDTV 480p, 720p 50/60, 1080i 50/60, 1080p 24/50/60 + 576p
PC graphic standard VGA, SVGA, XGA, SXGA, UXGA, WUXGA 10 bit Full Channel Signal Board Video Processing
CONNECTIVITY
Digital 2 x HDMI-HDCP vers. 1.4a
Analog 1 x Graphic RGBVH (VGA-UXGA) (D-sub 15 pin)
1 x Component - Analog YPbPr/RGBs/RGBHV (RCA)
1 x Composite Video
Control 1 x 3 pin MiniDIN (VESA STD) 3D Sync Out connector
1 x RJ45 LAN
1 x RS232 (D-sub 9 pin)
1 x USB connector Remote Control Port (Host Mode Only)
IR Receiver for Remote Control
Miscellaneous 3 x 12V 100mA output (via Jack) for On/Off Screen control 16:9/4:3, Anamorphic Lens
2 x 7-segment Displays for Status indications
8 keys keypad
GENERAL SPECIFICATIONS
Software control upgradable via RS232, serial interface or USB
Mains voltage range 100-240 +/-10% (48/62 Hz), standard DIN power connector
Power consumption maximum dual lamp operation: 900 W
maximum single lamp operation: 460 W
maximum when lamp cooling: 33W
stand-by: less than 1W
Projector dimensions (WxHxD) 464 x 241 x 564 mm
Projector Weight 27 Kg
Packaging dimensions (WxHxD) 564 x 341 x 664 mm
Packaging weight 32 Kg
ACCESSORIES
Supplied Installation and User Manual
AC power cords (2m - 6.6 ft)
Backlit remote control and batteries
Live Colors Calibration software 2.0
High Precision Probe
RS232 Adapter Cable; USB Wi-Fi adapter
Optional SIM2 VISUS Active Glasses (1)
Emitter
Projector ceiling bracket
Anamorphic lens systems (fixed or motorized)
CERTIFICATIONS
Standard EN 60950 - 1 Safety of information technology equipment, including electrical business equipment
UL 60950 & CAN/CSA-C22.2 No. 60950 Safety of Information Technology Equipment
RoHS + RoHS Cina
Marking CE, cULus, CCC
Electro Magnetic Compatibility EMISSION FCC, CFR 47, Part 15 SubpartB, Class B
EN 55022Information technology equipment – Radio disturbance characteristics – Limits and methods of measurement - Class B
Electro Magnetic Compatibility immunity EN 55024 Information technology equipment - Immunity characteristics - Limits and methods of measurement
ENV 50204
Numeric cellular phone electromagnetic field – Immunity Test
(1) A SIM2 3D emitter and glasses pack is required to initiate this feature (sold separately).

(2) ANSI Lumen Specification: This is the typical projector brightness specification found in most sales literature. This measurement allows for direct comparison with other manufacturer's projectors. Measurements are taken in a totally dark test room with T3 type lens (wide angle zoom settings), brand new lamp at full power, lamp's native white color temperature, internal test pattern (full white) and in compliance with ANSI IT7.228-1997 specification.
(3) Perfect Fit is optimized for M2 & M3 lenses. Cannot be used with short-throw M0 & M1 lenses.

(4) Lamp life: the hours quoted have been measured in a lab under ideal test conditions. Lamp life varies depending on usage conditions and the surrounding environment. This is an average value that cannot be guaranteed and is not protected by warranty.

The DLP® logo and DLP® medallion are trademarks of Texas Instruments. product specifications are subject to change without notice.

Due to constant product development, specifications and design might be subject to change without notice.
