DISPLAY
DLP® Type 3 Chip DMDs 0,95" 1080p DC4
Resolution 1920x1080 pixels
Lens High quality selected optic glass lenses
Special features PureAction 3D technology
Triple flash genuine 144hz cinema reproduction
PureAction 2D for fast action materials
Puremovie 2D
SIM2 DynamicBlack™ Technology enchanced solution (in 2D mode only)
Contrast ratio (Full ON/ Full OFF) up to30,000:1 with DynamicBlack™ Technology and EC lens type (in 2D mode only)
Lamp power 350W (dimmable)
Brightness(**) up to 5000 Ansi Lumens (adjustable) with HB lens
up to 3800 ANSI Lumens (adjustable) with EC lens type
Lamp life expectancy(*) 2000 hours typical in standard power mode; 3000 hours in ECO mode
INSTALLATION
Lens type High Brightness (HB)
Extended Contrast (EC)
Throw ratio standard lens 1.82-2.48:1 (type T2)
Throw ratio optional lenses 1.37-1.66:1 (typ. T1)
2.6-3.9:1 (typ. T3)
Optical shift Motorized, vertical up to +50%, down -10% max. from screen center (based on image height)
Digital keystone adjustment Vertical, +/-18˚
Picture size (inches diagonal) 50-300
Aspect ratio 4:3, 16:9 Anamorphic, LetterBox, Panoramic, Pixel to Pixel + 3 custom-user adjustments
ELECTRONICS AND CONNECTIVITY
Horizontal & vertical scan freq. 15-80kHz/24-144Hz
SDTV PAL (B,G,H,I,M,N,60); SECAM; NTSC autom. selected
HDTV 480p, 720p 50/60, 1080i 50/60, 1080p 24/50/60 + 576p
PC graphic standard VGA, SVGA, XGA, SXGA, UXGA, WUXGA 10 bit Full Channel Signal Board Video Processing
INPUTS/OUTPUTS
Digital 2 x HDMI-HDCP vers. 1.4a (v.1.4 with Deep Color)
Analog 1x Composite Video
1 x Graphic RGBVH (VGA-UXGA) (D-sub 15 pin)
1 x Component - Analog YPbPr/RGBs/RGBHV (RCA)
Control 3D Sync out
1 x RS232 (D-sub 9 pin)
1 x USB (B type)
Miscellaneous 3 x 12V 100mA output (via Jack)
GENERAL SPECIFICATIONS
Software control upgradable via RS232, serial interface or USB
Mains voltage range 100-240 +/-10% (48/62 Hz)
Projector Weight 11 Kg. or 24.3 lbs
Projector dimensions (WxHxD) 458x210x455 mm (18"x8.3"x17.9")
ACCESSORIES
Supplied Installation and User Manual
AC power cords (2m - 6.6 ft)
Backlit remote control and batteries
Live Colors Calibration software 2.0
Premium SIM2 VISUS Active Glasses (4 pcs.)
Emitter
Optional Projector ceiling bracket
Anamorphic lens systems (fixed or motorized)
Additional VISUS active glasses
(*) Lamp life: the hours quoted have been measured in a lab under ideal test conditions. Lamp life varies depending on usage conditions and the surrounding environment. This is an average value that cannot be guaranteed and is not protected by warranty.
(**)ANSI Lumen Specification: This is the typical projector brightness specification found in most sales literature. This measurement allows for direct comparison with other manufacturer's projectors. Measurements are taken in a totally dark test room with T3 type lens (wide angle zoom settings), brand new lamp at full power, lamp's native white color temperature, internal test pattern (full white) and in compliance with ANSI IT7.228-1997 specification.
Due to constant product development, specifications are subject to change without notice.
