Dane techniczne
Display features
Display typeOLED
Display specifications
Screen Size for WEB(diagonal, cm, integer or 1st decimal)164 cm
Display resolution (H x V, pixels)3840 x 2160
Screen Size (inch, measured diagonally)65"(64.5")
Viewing Angle (Right/Left)178(89/89) degree
Viewing Angle (Up/Down)178(89/89) degree
Display ResolutionQFHD
Aspect Ratio16:09
Professional features
HDMI Auto Wake UpNo
Compatible with TDM Digital Signage/ TEOS SolutionsNo
Operating SystemAndroid 10
On-board Storage (GB)16GB
Display system
TV System (Digital Terrestrial)DVB-T/T2
TV System (Digital Cable)DVB-C
TV System (Digital Sat)DVB-S/S2
Number of Tuners (Terrestrial/Cable)2(Digital)/1(Analog)
Number of Tuners (Sat)2
Network features
Apple AirPlayYes
Wi-Fi DirectYes
Wi-Fi CertifiedYes
Chromecast built-inYes
Internet BrowserVewd
Wireless LANIntegrated
Convenience features
USB playback codecsMPEG1:MPEG1/MPEG2PS:MPEG2/MPEG2TS(HDV,AVCHD):MPEG2,AVC/MP4(XAVC S): AVC,MPEG4,HEVC/AVI: Xvid,MotinJpeg/ASF(WMV): VC1/MOV: AVC,MPEG4,MotionJpeg/MKV: Xvid,AVC,MPEG4,VP8.
HEVC/WEBM:VP8/3GPP:MPEG4,AVC/MP3/ASF(WMA)/LPCM/WAV/MP4AAC/FLAC/JPEG WEBM:VP9/AC4/ogg/AAC/ARW(Screen nail only)
HDMI-CECYes
i-ManualYes
On Screen ClockYes
Sleep TimerYes
On/Off TimerYes
Display LanguageAFR,AMH,ARA,ASM,AZE,BEL,BUL,BEN,BOS,CAT,CZE,DAN,DEU,GRE,ENG,SPA,EST,BAQ,PER,FIN,FRA,GLG,GUJ,HIN,HRV,HUN,IND,ISL,ITA,HEB,JPN,KAZ,KAN,KOR,KIR,LAO,LIT,LAV,MAC,MAL,MON,MAR,MAY,BUR,NOB,NEP,NLD,ORI,PAN,POL,POR,RUM,RUS,SOL,SLV,ALB,SRP,SWE, SWA,TAM,TEL,THA,TGL,TUR,UKR,URD,UZB,VIE,zh_CN,zh_HK,zh_TW,ZUL
Control specs
IP ControlYes (Authentication required)
Pro ModeNo
Inputs & outputs
HDMI Signal4096x2160p(24,50,60Hz), 3840x2160p(24,25,30,50,60,100,120Hz) *1 , 1080p(30,50,60,100,120Hz), 1080/24p, 1080i(50,60Hz), 720p(30,50,60Hz), 720/24p, 576p, 480p
HDCPHDCP2.3(for HDMI1/2/3/4)
AC Power InputC18 INLET(REAR)
RF (Terrestrial/Cable) Connection Input(s)1(Bottom)
IF (Satellite) Input(s)2(Bottom)
Composite Video Input(s)Hybrid w/S-Center Speaker Input x1(Side, Mini jack)
HDMI inputs total4(1Side,3Bottom)
Digital Audio Output(s)1 (Bottom)
Audio Output(s)No
Headphone Output(s)1(side)
Ethernet inputs1(Bottom)
PCMCIA Slot(s)1(Side)
Audio specifications
Speaker PositionFront
Audio Power Output20W + 20W + 10W + 10W
Digital audio out (Optical) formatTwo channel linear PCM: 48kHz 16bits, Dolby Audio, DTS
HDMI Audio Return Channel(ARC)Yes (eARC/ARC)
HDMI input Audio format5.1 channel linear PCM: 32/44.1/48/88.2/96/176.4/192kHz 16/20/24bits, Dolby Audio, Dolby Atmos, DTS
ARC output formatTwo channel linear PCM: 48kHz 16bits, Dolby Audio, Dolby Atmos, DTS
Video specifications
Wide ModeWide zoom/Normal/Full/Zoom/14:9 Normal/Full1/Full2 for PC
4:3 DefaultYes
Video ProcessingXR 4K Upscaling
Motion enhancerXR Motion Clarity, Auto mode
4K ProcessorCognitive Processor XR
HDR (High Dynamic Range) compatiblityYes(HDR10,HLG,Dolby Vision)
Panel Refresh Rate (Native Hertz)100Hz
Dynamic Contrast EnhancerYes
Design features
Stand Position2way position(Standard position/Soundbar position)
Stand ColorTitanium Black
Bezel DesignSeamless Edge
Cable ManagementYes
Frame colorTitanium Black
Stand DesignAluminum Edge Stand
VESA® Hole Spacing CompatibleYes
VESA® Hole Pitch(W x H)30.0 x 30.0 cm
Eco & energy saving
On mode power 1000h SDR(New lot5)138 kWh/1000h
Mercury content(mg)0.0
Power Requirements (frequency)50Hz
Rated Power Consumption532 W
Power Consumption (in Standby)0.50 W
Power Requirements (voltage)220 V - 240 V AC
Power consumption(Networked Standby)2.00W(Wi-Fi) / 2.00W(LAN) / 0.50W(CEC)
Power Saving Mode / Back Light Off ModeYes
Dimensions
Display Only (W x H x D)Approx. 144.4 x 83.3 x 4.1(0.56) cm
Display with Stand (W x H x D)Approx. 150.2 x 83.4 x 31.7 cm
Package Carton (W x H x D)Approx. 159.4 x 95.9 x 18.0 cm
Weights (Approx.)
Display OnlyApprox. 22.5 kg
Display with StandApprox. 24.6 kg
Package Carton(Gross)Approx. 34 kg
Supplied accessories
Voice Remote ControlRMF-TX621E
BatteriesLR03
AC Power Cord SpecBundle (C17) (EUROPE) (2pin) (round pins Type B) + Bundle (C17) (SWISS) (2pin) (round pins Type C)
Operating InstructionsGB,FR,ES,NL,DE,PT,IT,SE,DK,FI,NO,PL,CZ,SK,HU,RO,BG,GR,TR,RU,UA,AR
Quick Setup Guide / Supplement CUE (GA)GB,FR,ES,NL,DE,PT,IT,DK,NO,SE,FI,PL,CZ,SK,HU,RO,BG,GR,TR,RU,UA,AR
Table Top StandSeparate(assembly required)
Optional accessories
Wallmount BracketSU-WL450(Terminal access limitation, refer to SU-WL450 product page), SU-WL850(Refer to Country/Area Handling Chart)
PrimeSupport
Included PrimeSupport3 Years warranty with Repair or if necessary advanced exchange handled by local partner, on premise where possible.
Optional PrimeSupport ExtensionsOptional 2-year support extension available: PSP.FWD65A90J.2X
Notes
*1100Hz and 120Hz is supported by HDMI IN 2, IN 3 and IN 4
