Technical Specifications

Display system
Display system 3 LCD system
Display device
Size of effective display area 0.79 inches (20.1 mm) x 3 BrightEra LCD Panel, Aspect ratio: 4:3
Number of pixels 2,359,296 (1024 x 768 x 3) pixels
Projection lens*1
Focus Manual
Zoom - Powered/Manual Manual
Zoom - Ratio Approx. x 1.6
Throw ratio 1.42:1 to 2.27:1
Lens shift - Powered/Manual Manual
Lens shift - Range Vertical + 51%
Lens shift - Range Horizontal +/- 33%
Light source
Type Ultra high pressure mercury lamp
Wattage 230 W type
Recommended lamp replacement time*1
Lamp mode: High 4000 H
Lamp mode: Standard 5000 H
Filter cleaning / replacement cycle (Max.)*2
Filter cleaning / replacement cycle (Max.) 15000 H (Cleaning)
Screen size*1
Screen size 40" to 600" (1.02 m to 15.24 m) (measured diagonally)
Light output
Lamp mode: High 4200 lm
Lamp mode: Standard 3000 lm
Color light output
Lamp mode: High 4200 lm
Lamp mode: Standard 3000 lm
Contrast ratio (full white / full black)*3
Contrast ratio (full white / full black)*3 2000:1
Displayable scanning frequency
Horizontal 14 kHz to 93 kHz
Vertical 47 Hz to 93 Hz
Display resolution
Computer signal input Maximum display resolution: 1920 x 1200 dots *4
Video signal input NTSC, PAL, SECAM, 480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p
Color system
Color system NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, PAL60
Keystone correction (Max.)
Vertical +/- 30 degrees
OSD language
OSD language 20-languages (English, Dutch, French, Italian, German, Spanish, Portuguese, Turkish, Polish, Russian, Swedish, Norwegian, Japanese, Simplified Chinese, Traditional Chinese, Korean, Thai, Vietnamese, Arabic, Farsi)
INPUT OUTPUT (Computer/Video/Control)
INPUT A RGB / YPbPr input connector: 5BNC (female)
Audio input connector: Stereo mini jack
INPUT B RGB input connector: Mini D-sub 15-pin (female)
Audio input connector: Stereo mini jack (shared with INPUT C)
INPUT C DVI-D input connector: DVI-D 24-pin (Single link), HDCP support
Audio input connector: Stereo mini jack (shared with INPUT B)
S VIDEO IN S video input connector: Mini DIN 4-pin
Audio input connector: Pin jack (x2) (shared with VIDEO IN)
VIDEO IN Video input connector: Pin jack
Audio input connector: Pin jack (x2) (shared with S VIDEO IN)
OUTPUT Monitor output connector*5: Mini D-sub 15-pin (female)
Audio output connector*6: Stereo mini jack (variable out)
REMOTE RS-232C connector: D-sub 9-pin (female)
LAN RJ-45, 10BASE-T/100BASE-TX
IR (Control S) Control S input connector: Stereo mini jack
Acoustic noise
Lamp mode: Standard 29 dB
Operating temperature / Operating humidity
Operating temperature / Operating humidity 0°C to 40°C (32°F to 104°F) / 35% to 85% (no condensation)
Storage temperature / Storage humidity
Storage temperature / Storage humidity -20°C to +60°C (-4°F to +140°F) / 10% to 90% (no condensation)
Power requirements
Power requirements AC 100 V to 240 V, 3.3 A to 1.3 A, 50/60 Hz
Power consumption
AC 100 V to 120 V Lamp mode: High: 330 W
AC 100 V to 120 V Lamp mode: High: 310 W
Power Consumption (Standby Mode)
AC 100 V to 120 V 0.2 W (when "Standby mode" is set to "Low)
AC 220 V to 240 V 0.3 W (when "Standby mode" is set to "Low")
Power Consumption (Networked Standby Mode)
AC 100 V to 120 V 11.0 W (LAN) (when "Standby Mode" is set to "Standard")
AC 220 V to 240 V 12.0 W (LAN) (when "Standby Mode" is set to "Standard")
Standby Mode / Networked Standby Mode Activated
Standby Mode / Networked Standby Mode Activated After about 10 Minutes
Heat dissipation
AC 100 V to 120 V 1126 BTU/h
AC 220 V to 240 V 1058 BTU/h
Dimensions (W x H x D)
Dimensions (W x H x D) (without protrusions) Approx. 390 x 134 x 463 mm (15 11/32 x 5 9/32 x 18 7/32 inches)
Mass
Mass Approx. 7.9 kg (17 lb)
Supplied accessories
Remote commander RM-PJ19
Optional accessories
Replacement lamp LMP-F230
Projection lenses VPLL-Z2009/Z1024/Z1032/2007
Projection lens adapter PK-F30LA1
Notes
*1 With supplied standard lens
*2 This figure is expected maintenance time, not guaranteed time. The actual value depends on the environment and how the projector is used.
*3 The value is average.
*4 Available for VESA Reduced Blanking signal.
*5 From INPUT A and INPUT B.
*6 Works as an audio switcher function. Output from a selected channel; not available in standby.
