Specyfikacja techniczna

Image Display

• Display System: 3-Chip 0.74" SXRD LCoS
• Native Chip Resolution: 4096 x 2160 (DCI 4K)
• Max Brightness: 2200 Lumens
• Aspect Ratio: Native: 17:9
• DLP Link 3D: Yes

Lens

Focus

Manual Powered

Lens Shift

Vertical: ± 80%

Horizontal: ± 31%

Optical Zoom

Powered: 2.1x

Throw Ratio

1.35 - 2.9:1

Projection Size

60 - 300" / 152.40 - 762.00 cm

Features

Input/Output Connectors

Inputs/Outputs

2 x HDMI (HDMI Type-A) Audio, Video Input

1 x Ethernet (RJ45) LAN

1 x 1/8" (3.5 mm) Mini Control Input

2 x 12 V Trigger Control Output

1 x RS-232C (DE-9) Control

1 x USB 2.0 (USB Type-A) Service Input

Memory Card Slot

None

General

Light Source

Laser Phosphor

Lamp Power

343 W

Expected Lamp Life

Medium Brightness: 20,000 Hours

Fan Noise

Medium Brightness: 26 dB

AC Input Power

100 to 240 VAC, 50 / 60 Hz

Power Consumption

Full Brightness: 490 W

Standby Mode (Lamp Off): <1 W

Operating Temperature

41 to 95°F / 5 to 35°C

Storage Temperature

10 to 140°F / -12 to 60°C

Operating Humidity

20 - 80%

Storage Humidity

20 - 80%

Dimensions (W x H x D)

22.0 x 9.1 x 20.1" / 560.0 x 230.0 x 510.0 mm With protrusions

22.0 x 8.8 x 19.5" / 560.0 x 223.0 x 496.0 mm Without protrusions

Weight

48.5 lb / 22.00 kg

Special Features: Anamorphic Ready, Full HD 3D, Frame Interpolation, Lens Memory, HDR, Infinite Black
