SPECIFICATIONS

• LCD PANEL

  Panel Size : 75"

  Type/ Tech : TFT LCD Module with LED Backlight

  Display Area (mm) : 1649.66(H) x 927.94(V)

  Aspect Ratio : 16:09

  Resolution : 3840 x 2160

  Colors : 1.07B colors (10bit)

  Brightness : 350 nits (typ.) 300 nits (min.)

  Contrast Ratio : 1200:1 (typ.)

  Response Time : 8 ms

  Viewing Angles : H = 178, V = 178 (typ.)

  Backlight : DLED

  Backlight Life : 30,000 Hours Min.

  Hardness : 7H

• INPUT

  HDMI : x 4

  RGB / VGA : x 1

  Audio : x 1

  CVBS (AV) : x 1

  YPbPr : x 1

  RS232 : x 1

  PC Slot : x 1 PC Slot

• OUTPUT

  HDMI : x 1 (for one of HDMI1/2/3)

  Audio (Earphone Out) : x 1

  SPIDF : x 1

  RS232 : x 1

• LAN

  RJ45 : x 1

• USB

  2.0 Type A : x 2 (side x1, top x1)

  3.0 Type A : x 2 (side)

• SPEAKERS

  20W x 2

• BUILT-IN PC

  Processor : ARM Cortex A53 Quad Core 1.5G Hz CPU

  Memory : 2GB

  Storage : 16GB

• COMPATIBILITY

  VGA : Refer to timing table

  HDMI : 480i, 480p,720p, 1080p, up to 2160p

  CVBS : 480i

• POWER

  Voltage : 100-240 VAC +/- 10% Wide Range, 50-60Hz +/-3 Hz

  Consumption : 300 W

• ERGONOMICS

  Wall Mount (VESA® ) : 600 x 400mm; Screw: M8 x 20mm

• OPERATING CONDITIONS

  Temperature (º C) : 32°F to 104°F (0°C to 40°C)

  Humidity : 10% ~ 90% non-condensing

• DIMENSIONS

  Physical W/o Stand (mm / Inch) : 1735.4 x 1014.0 x 93.2 mm / 68.32 x 39.92 x 3.67 inch

  Packaging (mm / Inch) : 1990 x 1165 x 320 mm / 78.35 x 51.77 x 13.78 in

• WEIGHT

  Net (kg / Lb) :  kg / lbs

  Net W/o Stand (kg / Lb) : 43.05 kg / 94.91lbs

  Gross (kg / Lb) : 65.40 kg / 144.18lbs

• REGULATIONS

  Standard : cTUVus, FCC, MX-CoC, Mexico Energy, CE, CB, RoHS, ErP, REACH, WEEE, CCC, China Energy Label
